TDA7297 Audio Amplifiers by Minos – Buy Online at XON
The Audio Amplifiers TDA7297 by Minos are compact, efficient, and reliable integrated audio power amplifiers designed for stereo applications. As part of the Semiconductors, Integrated Circuits - ICs, Audio ICs, Audio Amplifiers category, this dual-bridge amplifier delivers up to 15W per channel with minimal distortion, making it ideal for home audio systems, active speakers, and DIY projects.
1. Technical Specifications of TDA7297
-
Manufacturer: Minos
-
Part Number: TDA7297
-
Type: Audio Amplifiers
-
Output Power: 2 x 15W at 8O
-
Supply Voltage Range: 6V to 18V DC
-
THD: < 0.1% at 1kHz
-
Features: Short-circuit protection, thermal shutdown
-
Package: Multiwatt-15
-
Category: Semiconductors, Integrated Circuits - ICs, Audio ICs, Audio Amplifiers
This amplifier combines simplicity, performance, and reliability in a small form factor, suitable for a variety of low- to mid-power audio systems.
2. Key Features of TDA7297 Audio Amplifiers
-
Dual bridge output for high power stereo performance
-
Low total harmonic distortion for clean audio
-
Wide voltage range for flexible power supply options
-
Built-in thermal and short-circuit protection
-
Compact design for easy integration in audio equipment
3. Applications of TDA7297
4. Wiring and Connection Overview
Typical connection setup:
-
Power Supply: 6V–18V DC to Vcc pin
-
Audio Input: Connect to left/right input pins with biasing capacitors
-
Speaker Outputs: Left and right channel outputs to speakers
-
Ground: Common GND for power and signal return
5. Use Case Scenario – Active Speaker System
Scenario: A DIY audio builder wanted a low-cost, efficient amplifier for a compact active speaker setup.
Problem: Previous modules produced excessive heat and distortion at moderate volumes.
Solution: The TDA7297 Audio Amplifiers provided clean, distortion-free sound with integrated protection features.
Result: Improved sound clarity, longer speaker lifespan, and efficient power usage.
6. Download Datasheet for TDA7297
For full specifications, pin diagrams, and application examples:
Download TDA7297 Datasheet from Xon Electronics
7. Also Available from Other Manufacturers
The TDA7297 Audio Amplifiers are also available from:
8. Why Buy from Xon Electronics?
-
100% Genuine Audio ICs and Audio Amplifiers
-
Global shipping – USA, India, Australia, Europe & more
-
Bulk discounts for OEMs and hobbyists
-
Technical assistance for integration
-
Secure online ordering
9. FAQs – TDA7297 Audio Amplifiers
Q1: What is the maximum output power?
A: 2 x 15W at 8O load.
Q2: Is it suitable for DIY projects?
A: Yes, it’s widely used in DIY stereo amplifiers.
Q3: Does it include built-in protection?
A: Yes, it has thermal shutdown and short-circuit protection.
Q4: Can it run on 12V DC?
A: Yes, 12V DC is a common supply voltage for this IC.
Q5: Where can I buy it globally?
A: At www.xonelec.com with worldwide delivery.
Conclusion
The TDA7297 Audio Amplifiers by Minos offer a balance of power, efficiency, and audio quality. Ideal for home audio, active speakers, and custom projects, they are available now at Xon Electronics with global shipping to USA, India, Australia, Europe, and more.
