UC3843AN Switching Controllers by SLKORMICRO – High-Speed PWM Power Control
The Switching Controllers UC3843AN by SLKORMICRO are current-mode PWM control ICs tailored for efficient power conversion. Built for high-speed performance, low start-up current, and precision voltage regulation, this component is a trusted choice for modern switch-mode power supply (SMPS) and DC-DC converter applications.
This blog explores the technical specs, use cases, and integration benefits of the UC3843AN, along with a look at other available options from Texas Instruments.
Technical Specifications of UC3843AN
-
Manufacturer: SLKORMICRO
-
Part Number: UC3843AN
-
Function: Current-Mode PWM Switching Controller
-
Input Voltage Range: 7.6V – 30V
-
Start-Up Current: <1 mA
-
Operating Frequency: Up to 500kHz
-
Output Type: Totem-pole
-
Package Type: DIP-8
-
Category: Semiconductors, Integrated Circuits - ICs, Power Management ICs, Voltage Regulators & Voltage Controllers, Switching Controllers
This IC is optimized for energy-efficient power supplies across a wide range of applications.
Key Features of UC3843AN Switching Controllers
-
Current-Mode PWM Control with Fast Loop Response
-
Trimmed Internal Reference (5V ±1%)
-
Undervoltage Lockout (UVLO) with hysteresis
-
Totem-Pole Output Drive for MOSFETs
-
Low Start-Up and Operating Power Consumption
These features make the UC3843AN Switching Controllers ideal for designs requiring tight voltage regulation and rapid transient response.
Applications of UC3843AN
This IC integrates seamlessly into systems requiring robust voltage regulators & voltage controllers, and is commonly used in power management ICs.
Wiring and Connection Overview
Pin Configuration (DIP-8):
-
Pin 1: Compensation
-
Pin 2: Voltage Feedback
-
Pin 3: Current Sense
-
Pin 4: Timing (RT/CT)
-
Pin 5: GND
-
Pin 6: Output
-
Pin 7: VCC
-
Pin 8: Reference (VREF)
Its minimal external component requirement and high reliability make it a preferred option for efficient switching controller design.
Use Case Scenario: Optimizing Power in Embedded Controllers
Challenge: An embedded systems designer needed a compact and stable voltage regulation IC for their control units in industrial robotics.
Solution: The UC3843AN enabled accurate voltage control, improved energy efficiency, and reduced component footprint.
Result: Enhanced overall reliability and regulatory compliance using just one power management IC.
