USB6B1RL ESD Suppressors/TVS Diodes by TECH PUBLIC – Reliable Electrostatic Discharge Protection
The ESD Suppressors/TVS Diodes USB6B1RL by TECH PUBLIC provide high-performance protection for data and power lines against electrostatic discharge (ESD) and transient voltage spikes. Specially designed for high-speed USB and other communication lines, these compact suppressors ensure system-level reliability in a wide variety of electronic devices.
In this blog, we’ll explore the technical details, features, application areas, connection guidance, and a real-world use case to highlight the benefits of integrating these ESD Suppressors/TVS Diodes into your Circuit Protection design.
Technical Specifications of USB6B1RL
-
Manufacturer: TECH PUBLIC
-
Part Number: USB6B1RL
-
Device Type: ESD Suppressors/TVS Diodes
-
Reverse Stand-off Voltage (VR): 5V
-
Clamping Voltage: 9.8V (typical)
-
Peak Pulse Current (8/20 µs): 3A
-
Capacitance: Low (30pF typ.) for high-speed data lines
-
Response Time: <1ns
-
Mounting Type: Surface Mount (SOT-23-3 Package)
-
Category: Circuit Protection, ESD Suppressors/TVS Diodes
Designed for low-capacitance applications, the USB6B1RL ensures fast and accurate voltage suppression for USB, HDMI, and other high-speed interfaces.
Key Features of USB6B1RL ESD Suppressors/TVS Diodes
-
Ultra-Fast Response Time – Sub-nanosecond reaction to ESD events
-
Low Capacitance Design – Ideal for preserving USB and signal integrity
-
Surface-Mount Package – Easy integration into compact circuit boards
-
ESD Protection Up to ±15kV – Meets or exceeds IEC 61000-4-2 standards
-
Effective Clamping – Minimizes risk of damage from transient spikes
With robust protection and excellent performance, these ESD Suppressors/TVS Diodes are an essential component in advanced Circuit Protection strategies.
Applications of USB6B1RL
The USB6B1RL ESD Suppressors/TVS Diodes are suitable for:
-
USB 2.0 and USB 3.x Ports
-
HDMI, VGA, and DVI Interfaces
-
Ethernet and Network Equipment
-
Mobile Phones and Portable Devices
-
Industrial Controls and Embedded Systems
-
Consumer Electronics and IoT Devices
From data lines to power rails, these diodes offer broad Circuit Protection coverage in modern digital and communication systems.
Wiring and Connection Overview
-
Pin 1: Signal Line Input
-
Pin 2: Ground
-
Pin 3: Signal Line Output
-
Polarity: Bidirectional for symmetrical protection
-
Placement: Position close to the I/O connector for maximum ESD effectiveness
This configuration ensures optimal suppression performance while maintaining the integrity of high-speed signal transmission—an essential requirement for any Circuit Protection solution.
Use Case Scenario: USB Port Protection in Smart Home Devices
Scenario: A smart thermostat manufacturer was experiencing frequent field failures due to ESD events from USB servicing ports.
Problem: Static discharge during maintenance caused internal circuit malfunctions and system resets.
Solution: The team integrated USB6B1RL ESD Suppressors/TVS Diodes to protect the USB interface from direct and indirect ESD hits.
Result: Field reliability improved significantly, and product returns dropped by over 40%, reinforcing the importance of ESD Suppressors/TVS Diodes in all exposed interface designs.
