MS3470L12-3P-LC Amphenol

Amphenol MIL-DTL-26482, Series 2, Matrix TABLE OF CONTENTS MIL-DTL-26482, Series 2, Matrix Design Characteristics, Customer Options . 333 Insert Availability and Identification, Alternate Positioning . 334 Insert Arrangement Drawings 335, 336 Class Descriptions, Performance Specifications . 337 How to Order (Military and Commercial) 338 Shell Styles: Wall Mounting Receptacle with Narrow Flange, Wall Mounting Receptacle with Wide Flange 339 Cable Connecting Receptacle, Jam Nut Receptacle 340 Straight Plug, Straight Plug with RFI Grounding Fingers . 341 Contacts and Tools: Contact Information, Sealing Plugs, Crimping and Insertion/Removal Tools 342 Assembly Instructions . 343, 344 Additional MIL-DTL-26482 Connectors Brief Description of Commercial/Military MIL-DTL-26482, Series 1 345 (Covered in-depth in Amphenol Industrial Catalog 12-070) MIL-DTL-26482 Series 2, Matrix Typical Markets: Military & Commercial Aviation - Cockpit, Landing Gear, Aircraft Frame Military Aircraft Carriers Amphenol Instrumentation/Process Control/Test Equipment Aerospace C4ISR 332 Contact Amphenol Aerospace for more information at 800-678-0141 www.amphenol-aerospace.comEMI Filter 26482 83723 III 26500 5015 22992 Back- Options Matrix 2 Matrix Pyle Pyle Crimp Rear Class L Transient Shells Others Release Matrix MIL-DTL-26482, Series 2, Matrix Amphenol Aerospace Bayonet Coupling Connectors With Crimp Rear Release Contacts 38999 III Amphenol Aerospace offers the Matrix Product line of HD MIL-DTL-26482*, Series 2 connectors. Dualok This series provides a bayonet coupling connector with crimp II rear insertable, rear releasable contacts. I DESIGN CHARACTERISTICS SJT MS3470 Medium size, environmentally resistant connector wall mounting receptacle Accessories Recommended operating voltage to 1,000 VAC (RMS) with narrow flange Aquacon at sea level MS3472 Herm/Seal Quick positive coupling assured by 3 point bayonet wall mounting receptacle coupling system PCB with wide flange Visual confirmation of complete coupling HIHg Eliminates mismating by the use of five key/keyway design SPEED Insertion and removal of contacts from the rear of the Fiber connector assures no damage to the front that might aff ect Optics the sealing characteristics Utilizes same standard qualified rear-release type plastic Contacts Connectors tool for contact insertion and removal Cables Contacts are qualified to SAE AS39029** requirements BIN coded (three color bands), and are crimped with MS3471 standard crimp tools per MIL-DTL-22520 cable connecting recep- Grommets are constructed of tear-resistant elastomer tacle and experience no degradation when exposed to a broad range of fluids Sealing over a range of wire diameters is assured by a triple webbed grommet at the rear of the connector Closed entry socket side of the insert is designed with a lead-in chamfer and a hard face that will accept a pin con tact bent within pre-established limits Elastomer interfacial seal on the pin side has raised barri ers around each pin which displace into the socket MS3474 cham fer when mated, providing a positive moisture seal jam nut receptacle CUSTOMER OPTIONS Shell styles within this family include: Wall mount with either a narrow or a wide flange, jam nut single hole mount, and cable connecting receptacles, along with standard plugs or plugs with RFI grounding fin gers, in shell sizes 8 to 24 MS and Proprietary versions available Accommodation of contact sizes 20, 16 and 12 34 insert arrangement patterns available, accommodating MS3476 from a minimum of 3 to a maximum of 55 circuits straight plug Alternate positioning available MS3475 Various finishes are available (for information on plug with RFI grounding non-cad mium zinc alloy plating, consult Amphenol fingers Aerospace) * MIL-DTL-26482 supersedes MIL-C-26482 ** SAE AS39029 supersedes MIL-C-39029 Contact Amphenol Aerospace for more information at 800-678-0141 www.amphenol-aerospace.com 333
