DS28E17K# Analog Devices

DS28E17 Evaluation System Evaluates: DS28E17 General Description Benefits and Features The DS28E17 evaluation system (EV system) provides Driver Support for Windows 8 and Windows 7 the special hardware and software system to exercise the Fully Compliant with USB Specification v2.0 2 features of the DS28E17 1-Wire -to-I C master bridge IC. USB Powered with No External Power Supply The EV system consists of a DS28E17 EV kit board and a Required DS9481P-300 USB-to-1-Wire adapter for PC connectivity. 2 On-Board DS7505 Digital Thermometer I C The EV kit is compatible with Windows operating systems. Slave Peripheral EV System Contents 2 Extended I C Peripheral Module Connector for 2 DS28E17 EV Kit Board (Figure 1) Rapid Prototyping of I C Slaves DS9481P-300 USB-to-1-Wire Adapter (Figure 2) Proven PCB Layout Figure 1. DS28E17 EV Kit Board Figure 2. DS9481P-300 USB-to-1-Wire Adapter 1-Wire is a registered trademark of Maxim Integrated Products, Ordering Information appears at end of data sheet. Inc. Windows is a registered trademark and registered service mark of Microsoft Corporation. 19-7686 Rev 0 6/15DS28E17 Evaluation System Evaluates: DS28E17 2 PC USB Port DS9481P-300 DS28E17EV KIT I C Slave Device(s) Figure 3. Typical Setup 5) Open the DeviceDriver folder. DS28E17EVKIT Files 6) Right-click on install.bat and then choose Run as FILE DESCRIPTION administrator (Figure 5). DS28E17 EV Kit EV Kit Software 7) A command window opens with a prompt asking to install the device driver (Figure 6). Click Install. Quick Start 8) Open the folder where the DS28E17 EV kit software Required Equipment was extracted and double-click the Setup.exe file. DS28E17 EV kit (included) 9) Plug the USB cable to the DS9481P-300 adapter. DS9481P-300 USB-to-1-Wire adapter (included) 10) Insert the DS9481P-300 into a spare USB port on the PC. PC with a Windows 8 or Windows 7 (32-bit or 64-bit) operating system and a spare USB 2.0 or higher port 11) The device will automatically search and install the driver (Figure 7). 1-Wire drivers 12) Click on the Install button to start installation DS28E17 evaluation software (Figure 9). Note: In the following sections, software-related items are 13) To start the evaluation software, ensure that the identified by bolding. Text in bold refers to items directly DS9481P-300 has been properly installed and the from the EV kit software. Text in bold and underlined DS28E17 board and DS9481P-300 adapter are refers to items from the Windows operating system. connected. Procedure a. Run the DS28E17 EV kit software: Start The EV kit is fully assembled and tested. Follow the steps Programs Maxim Integrated DS28E17EV Kit below to verify board operation: 14) If the DS9481P-300 is not detected or connected 1) Install the 1-Wire drivers (see the Installing to the USB port, the software displays an error DS9481P-300 and 1-Wire Drivers section for message (Figure 10). Close the program window, instructions). reconnect the DS9481P-300 adapter and restart the program again. 2) Attach the DS9481P-300 adapter to the DS28E17 EV kit (Figure 4). 15) Once properly installed, the initial screen graphical user interface (GUI) should appear (Figure 11). 3) Visit
