PI3CH800 8-Bit Bus Switch, Enable Low 1.8V/2.5V/3.3V, High-Bandwidth, Hot Plug Features Description - - Applications Pin Configuration Block Diagram TSSOP TQFN QSOP (1) Pin Description Truth Table Pin No Pin Name Description Ax Function EN 1111111 19 Switch Enables EN H Hi-Z Disconnect 2, 3, 4, 5, 6, L Bx Connect A0-A7 A Ports 7, 8, 9 Note: 10 GND Ground 1. H=High Voltage Level L=Low Voltage Level Hi-Z=High Impedance 11, 12, 13, 14, 15, 16, B0-B7 B Ports 17, 18 20 V Power CC PI3CH800 www.diodes.com March 2018 Document Number DS40809 Rev 1-2 Diodes Incorporated 1 PI3CH800 Maximum Ratings Note: o o Stresses greater than those listed under MAXIMUM Storage Temperature ................................................................................... -65 C to +150 C RATINGS may cause permanent damage to the device. Ambient Temperature with Power Applied........................................ 40C to +85C This is a stress rating only and functional operation of the Supply Voltage to Ground Potential ............................................................ -0.5V to + 4.6V device at these or any other condi-tions above those DC Input Voltage ............................................................................................ -0.5V to + 6.0V indicated in the operational sec-tions of this specification DC Output Current .......................................................................................... 120mA is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability. Power Dissipation .............................................................................................................. 0.5W DC Electrical Characteristics 3.3V supply (Over operating range, T = -40 ~ +85C, V =3.3V10%, unless otherwise noted) A CC (1) (2) Symbol Description Test Conditions Min Typ Max Unit V Control Input HIGH Voltage Guaranteed Logic HIGH Level 2.0 - - V IH V Control Input LOW Voltage Guaranteed Logic LOW Level -0.5 - 0.8 V IL V Clamp Diode Voltage V = Min., I = -18mA - -1.3 -1.8 V IK CC IN I Input HIGH Current V = Max., V = V - - 1 A IH CC IN CC I Input Low Current V = Max., V = GND - - 1 A IL CC IN I High-Impedance Current 0 A, B V - - 1 A OZH CC V = Min., V = 0.0V CC IN - 4 6 I = -48mA or -64mA (3) ON R Switch On-Resistance ON V = Min., V = 3.6V CC IN - 5 8 I = -15mA ON Notes: 1. For Max. or Min. conditions, use appropriate value specified under Electrical Characteristics for the applicable device type. 2. Typical values are at V = 3.3V, T = 25C ambient and maximum loading. CC A 3. Measured by the voltage drop between A and B pin at indicated current through the switch. On-Resistance is determined by the lower of the voltages on the two (Ax, Bx) pins. 2.5V supply (Over operating range, T = -40 ~ +85C, V =2.5V10%, unless otherwise noted) A CC (1) (2) Symbol Description Test Conditions Min Typ Max Unit V Control Input HIGH Voltage Guaranteed Logic HIGH Level 1.8 - V +0.3 V IH CC V Control Input LOW Voltage Guaranteed Logic LOW Level -0.3 - 0.8 V IL V Clamp Diode Voltage V = Max., I = -6mA - -0.7 -1.8 V IK CC IN I Input HIGH Current V = Max., V = V - - 1 A IH CC IN CC I Input Low Current V = Max., V = GND - - 1 A IL CC IN I High-Impedance Current 0 A, B V - - 1 A OZH CC V = Min., V = 0.0V CC IN - 4 8 I = -48mA (3) ON R Switch On-Resistance ON V = Min., V = 2.25V CC IN - 7 14 I = -15mA ON Notes: 1. For Max. or Min. conditions, use appropriate value specified under Electrical Characteristics for the applicable device type. 2. Typical values are at V = 2.5V, T = 25C ambient and maximum loading. CC A 3. Measured by the voltage drop between A and B pin at indicated current through the switch. On-Resistance is determined by the lower of the voltages on the two (Ax, Bx) pins. PI3CH800 www.diodes.com March 2018 Document Number DS40809 Rev 1-2 Diodes Incorporated 2
