SECTION 1 INDUSTRIAL CONTROL AND GENERAL PURPOSE ENCLOSED TRANSFORMERS HPS Imperator , HPS Spartan , HPS Fusion and Q Series Transformers Control Transformer Quick Selection Charts ................................................. 28 What Is A Control Transformer ........................................................................ 29 Overcurrent Protection ........................................................................................ 30 HPS Imperator Machine Tool Industrial Control Transformers Features and Benefits ............................................................................................ 34 Selection Tables ...................................................................................................... 36 Optional Accessories .............................................................................................. 43 Wiring Schematics ................................................................................................. 63 HPS Spartan Industrial Open-Style Core & Coil Control Transformers Features and Benefits ........................................................................................... 46 Selection Tables ...................................................................................................... 47 Optional Accessories ............................................................................................ 52 Wiring Schematics ................................................................................................. 74 HPS Fusion General Purpose Enclosed Transformers Features and Benefits ........................................................................................... 54 Selection Tables ...................................................................................................... 55 Optional Accessories ............................................................................................ 60 Wiring Schematics ................................................................................................. 74 Q Series Enclosed Potted Control Transformers Features and Benefits .............................................................................................. 61 Selection Table .......................................................................................................... 62 Wiring Schematics ................................................................................................... 244SECTION 1 TRANSFORMER QUICK SELECTION CHARTS HPS Imperator Pri. Volts Sec. Volts Group Part No. Page 600, 575, 550 120 x 240, 115 x 230, 110 x 220 A PH***AJ 36 600, 575, 550 12 x 24, 11.5 x 23, 11 x 22 B PH***AR 36 240 x 480, 230 x 460, 220 x 440 120 x 240, 115 x 230, 110 x 220 C PH***MQMJ 37 240 x 480, 230 x 460, 220 x 440 12 x 24, 11.5 x 23, 11 x 22 D PH***QR 37 208 x 416, 200 x 400, 190 x 380 120 x 240, 115 x 230, 110 x 220 E PH***SP 38 120 x 240, 115 x 230, 110 x 220 120 x 240, 115 x 230, 110 x 220 F PH***PP 38 120 x 240, 115 x 230, 110 x 220 12 x 24, 11.5 x 23, 11 x 22 G PH***PG 39 600/480/240, 575/460/230, 550/440/220 120/100, 115/95, 110/90 H PH***MBMH 39 480/240, 460/230/208, 440/220/200 120/25, 115/24, 110/23 I PH***MLI 40 415/400/380 110 x 220 J PH***MEMX 40 380/277/208 120 x 240 K PH***MGJ 41 HPS Spartan Pri. Volts Sec. Volts Group Part No. Page 600/480, 575/460, 550/440 120 x 240, 115 x 230, 110 x 220 A SP***ACP 47 600, 575, 550 12 x 24, 11.5 x 23, 11 x 22 B SP***AR 47 240 x 480, 230 x 460, 220 x 440 120 x 240, 115 x 230, 110 x 220 C SP***MQMJ 48 240 x 480, 230 x 460, 220 x 440 12 x 24, 11.5 x 23, 11 x 22 D SP***QR 48 347/380 120 x 240 E SP***KHP 49 347/380 12 x 24 F SP***KHR 49 277 120 G SP***NJ 50 120 x 240, 115 x 230, 110 x 220 12 x 24, 11.5 x 23, 11 x 22 H SP***PR 50 208 x 416, 200 x 400, 190 x 380 120 x 240, 115 x 230, 110 x 220 I SP***SP 51 208 x 416, 200 x 400, 190 x 380 12 x 24, 11.5 x 23, 11 x 22 J SP***SR 51 HPS Fusion Pri. Volts Sec. Volts Group Part No. Page 600/480, 575/460, 550/440 120 x 240, 115 x 230, 110 x 220 A FS***ACP 55 600, 575, 550 12 x 24, 11.5 x 23, 11 x 22 B FS***AR 55 240 x 480, 230 x 460, 220 x 440 120 x 240, 115 x 230, 110 x 220 C FS***MQMJ 56 240 x 480, 230 x 460, 220 x 440 12 x 24, 11.5 x 23, 11 x 22 D FS***QR 56 347/380 120 x 240 E FS***KHP 57 347/380 12 x 24 F FS***KHR 57 277 120 G FS***NJ 58 120 x 240, 115 x 230, 110 x 220 12 x 24, 11.5 x 23, 11 x 22 H FS***PR 58 208 x 416, 200 x 400, 190 x 380 120 x 240, 115 x 230, 110 x 220 I FS***SP 59 208 x 416, 200 x 400, 190 x 380 12 x 24, 11.5 x 23, 11 x 22 J FS***SR 59 Q Series Pri. Volts Sec. Volts Part No. Page 600 12/24 Q***PRC* 62 28 Data subject to change without notice. Hammond Power Solutions Inc. SECTION 1
