X7R Dielectric General Specifications X7R formulations are called temperature stable ceramics and fall into EIA Class II materials. X7R is the most popular of these intermediate dielectric constant materials. Its temperature variation of capacitance is within 15% from -55C to +125C. This capacitance change is non-linear. Capacitance for X7R varies under the influence of electrical operating con-ditions such as voltage and frequency. X7R dielectric chip usage covers the broad spectrum of industrial applications where known changes in capacitance due to applied voltages are acceptable. PART NUMBER (SEE PAGE 4 FOR COMPLETE PART NUMBER EXPLANATION) 0805 5 103 M A T 2 A Size Voltage Dielectric Capacitance Capacitance Failure Terminations Packaging Special (L x W) 4V = 4 X7R = C Code (In pF) Tolerance Rate T = Plated Ni and Sn 2 = 7 Reel Code ** 6.3V = 6 2 Sig. Digits + J = 5%* A = Not Z= FLEXITERM 4 = 13 Reel A = Std. 10V = Z Number of Zeros K = 10% Applicable Product *Optional termination Contact 16V = Y M = 20% Factory For 25V = 3 **See FLEXITERM Multiples 50V = 5 X7R section *1F only, 100V = 1 contact factory for 200V = 2 additional values 500V = 7 NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers. Contact factory for non-specified capacitance values. The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. 19 100819 surface mount ceramic capacitor products X7R Dielectric Specifications and Test Methods Parameter/Test X7R Specification Limits Measuring Conditions Operating Temperature Range -55C to +125C Temperature Cycle Chamber Capacitance Within specified tolerance Freq.: 1.0 kHz 10% 10% for 50V DC rating 12.5% for 25V DC rating Voltage: 1.0Vrms .2V 12.5% for 25V and 16V DC rating Dissipation Factor For Cap > 10F, 0.5Vrm 120Hz 12.5% for 10V DC rating Contact Factory for DF by PN 100,000M or 1000M - F, Charge device with rated voltage for Insulation Resistance whichever is less 120 5 secs room temp/humidity Charge device with 250% of rated voltage for 1-5 seconds, w/ Dielectric Strength No breakdown or visual defects charge and discharge current limited to 50 mA (max) Note: Charge device with 150% of rated voltage for 500V devices. Appearance No defects Capacitance 12% Variation Resistance to Deflection: 2mm Flexure Dissipation Test Time: 30 seconds Meets Initial Values (As Above) Stresses Factor Insulation Initial Value x 0.3 Resistance 95% of each terminal should be covered with Dip device in eutectic solder at 230 5C Solderability fresh solder for 5.0 0.5 seconds Appearance No defects, <25% leaching of either end terminal Capacitance 7.5% Variation Dissipation Dip device in eutectic solder at 260C for 60 seconds. Store at Meets Initial Values (As Above) Resistance to Factor room temperature for 24 2hours before measuring electrical Solder Heat properties. Insulation Meets Initial Values (As Above) Resistance Dielectric Meets Initial Values (As Above) Strength Appearance No visual defects Step 1: -55C 2 30 3 minutes Capacitance 7.5% Step 2: Room Temp 3 minutes Variation Dissipation Meets Initial Values (As Above) Step 3: +125C 2 30 3 minutes Thermal Shock Factor Insulation Meets Initial Values (As Above) Step 4: Room Temp 3 minutes Resistance Dielectric Repeat for 5 cycles and measure after 24 2 hours at room Meets Initial Values (As Above) Strength temperature Appearance No visual defects Pre-treatment: After mounting, perform heat treatment 150+0/- 10C for 2 hour, then stabilise for 24+/-2 hour at room temp, Capacitance 12.5% then measure. Variation Dissipation Initial Value x 2.0 (See Above) Charge device with rated voltage in test chamber set at Factor 125C 2C for 1000 hours (+48, -0). Insulation Load Life Initial Value x 0.3 (See Above) Resistance Pre-treatment: After remove from test chamber, perform heat treatment 150+0/-10C for 2 hour, then stabilise for 24+/-2 hour Dielectric at room temp, then measure. Meets Initial Values (As Above) Strength Contact KYOCERA AVX for datasheet of specific parts. Appearance No visual defects Pre-treatment: After mounting, perform heat treatment 150+0/- 10C for 2 hour, then stabilise for 24+/-2 hour at room temp, Capacitance 12.5% then measure. Variation Dissipation Initial Value x 2.0 (See Above) Load Store in a test chamber set at 85C 2C/ 85% 5% relative Factor Humidity humidity for 1000 hours (+48, -0) with rated voltage applied. Insulation Initial Value x 0.3 (See Above) Resistance Pre-treatment: After remove from test chamber, perform heat Dielectric treatment 150+0/-10C for 2 hour, then stabilise for 24+/-2 hour Meets Initial Values (As Above) Strength at room temp, then measure. The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. 20 073021 surface mount ceramic capacitor products
