MSMBJ51CA Microchip

MSMBG5.0A MXLSMBG170CAe3, MSMBJ5.0A MXLSMBJ170CAe3 Screening in 600 Watt Surface Mount reference to Available MIL-PRF-19500 Transient Voltage Suppressor available DESCRIPTION The MSMB 5.0A MSMB 170CA series of surface mount 600 watt transient voltage suppressors provide a selection of standoff voltages (Vwm) from 5.0 to 170 V. These high-reliability devices are available in either unidirectional or bidirectional versions. The SMBG Gull-wing design in the DO- 215AA package is ideal for visible solder connections. The SMBJ J-bend design in the DO- 214AA package allows for greater PC board mounting density. It is available with SnPb or RoHS compliant matte-tin plating. DO-215AA Important: For the latest information, visit our website MSMBG5.0A MXLSMBG170CAe3, MSMBJ5.0A MXLSMBJ170CAe3 MECHANICAL and PACKAGING CASE: Void-free transfer molded thermosetting epoxy body meeting UL94V-0 requirements. TERMINALS: Tin-lead or RoHS compliant annealed matte-tin plating readily solderable per MIL- STD-750, method 2026. MARKING: Part number. POLARITY: Cathode end banded. TAPE & REEL option: Standard per EIA-481-1-A (add TR suffix to part number). Consult factory for quantities. WEIGHT: Approximately 0.1 grams. See Package Dimensions on last page. PART NOMENCLATURE M SM B G 5.0 C A e3 Reliability Level* RoHS Compliance M e3 = RoHS Compliant MA Blank = non-RoHS Compliant MX MXL +/- 5% Tolerance Level *(see High Reliability Up- Screened Plastic Products Polarity Portfolio) C = bidirectional Blank = unidirectional Surface Mount Package Stand-Off Voltage (V ) WM 600 W Power Level (see Electrical Characteristics table) Lead Form G = Gull-Wing J = J-Bend SYMBOLS & DEFINITIONS Symbol Definition Working Peak (Standoff) Voltage - The maximum peak voltage that can be applied over the operating temperature V WM range. This is also referred to as standoff voltage. P Peak Pulse Power - Rated random recurring peak impulse power dissipation. PP V Breakdown Voltage - The minimum voltage the device will exhibit at a specified current. ( BR) I Standby Current - The current at the rated standoff voltage (V ). D WM I PP Peak Pulse Current - The peak current during the impulse. Clamping Voltage - Clamping voltage at I (peak pulse current) at the specified pulse conditions (typically shown as PP V C maximum value). I Breakdown Current The current used for measuring breakdown voltage V . BR ( BR) RF01000, Rev. C (1/4/13) 2013 Microsemi Corporation Page 2 of 7
