Product Information

4715SL-05W-B70-D00

4715SL-05W-B70-D00 electronic component of MinebeaMitsumi

Datasheet
DC Fan Axial Ball Bearing 24V 15V to 25.2V 201CFM 62.3dB 119 X 119 X 38.4mm
Manufacturer: MinebeaMitsumi
Large
This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges



Price (USD)
N/A

Shipping Restricted

 More Buying Options & Price Grid(s)

Availability Price Quantity
0 - WHS 1

MOQ : 1
Multiples : 1

Stock Image

4715SL-05W-B70-D00
MinebeaMitsumi

1 : USD 57.1354
10 : USD 51.4427
25 : USD 50.9465
100 : USD 50.4112
N/A

Shipping Restricted
0 - WHS 2

MOQ : 1
Multiples : 1

Stock Image

4715SL-05W-B70-D00
MinebeaMitsumi

1 : USD 60.4831
5 : USD 54.7312
10 : USD 48.9888
25 : USD 44.8232
N/A

Shipping Restricted
0 - WHS 3

MOQ : 40
Multiples : 40

Stock Image

4715SL-05W-B70-D00
MinebeaMitsumi

40 : USD 48.8957
N/A

Shipping Restricted

Read More Specifications


Manufacturer
Product Category
Height
Width
Supply Voltage
Operating Supply Voltage
Airflow
Speed
Bearing Type
Power Rating
Frame Dimensions - mm
Housing Material
Termination Style
Product Range
Fan Frame Size
External Depth
Flow Rate - Imperial
Flow Rate - Metric
Noise Rating
Length
Pressure Type
Brand
Current Type
Cnhts
Hts Code
Product Type
Factory Pack Quantity :
Subcategory
Taric
Tradename
LoadingGif

Notes:- Show Stocked Products With Similar Attributes.

More Products By Manufacturer "Minebeamitsumi"

Image Description
5915PC-12T-B20-A00 electronic component of MinebeaMitsumi 5915PC-12T-B20-A00

AC Fan Ball Bearing 115V 0.2A/0.21A 21W/22W 50Hz/60Hz 2200RPM/2600RPM 141.2CFM/166CFM 46dB/50dB Flange Mount
Stock : 0

5910PL-05W-B70-L00 electronic component of MinebeaMitsumi 5910PL-05W-B70-L00

DC Fan Ball Bearing 24V 1.55A 37.2W 4100RPM 290CFM 65.4dB Flange Mount
Stock : 27

4715TS-23T-B5A-A00 electronic component of MinebeaMitsumi 4715TS-23T-B5A-A00

AC Fans Axial Fan, 119x38mm, 230VAC, 98.84CFM, Flange, Terminals, Metal Blades/Standard
Stock : 0

4715VL-05W-B80-E00 electronic component of MinebeaMitsumi 4715VL-05W-B80-E00

DC Fan Axial Ball Bearing 24V 18V to 27.6V 243.2CFM 66dB 120 X 120 X 38mm
Stock : 47

4715TS-12T-B50-AM0 electronic component of MinebeaMitsumi 4715TS-12T-B50-AM0

AC Fan Axial Ball Bearing 115V 98.84CFM/116.49CFM 46dB/50dB 119 X 119 X 38mm
Stock : 0

4715TS-12T-B5A-A00 electronic component of MinebeaMitsumi 4715TS-12T-B5A-A00

AC Fans Axial Fan, 119x38mm, 115VAC, 98.84CFM, Flange, Terminals, Metal Blades/Standard
Stock : 0

5915PC-12T-B10-A00 electronic component of MinebeaMitsumi 5915PC-12T-B10-A00

AC Fan Ball Bearing 115V 0.16A/0.19A 16W/18W 50Hz/60Hz 1400RPM/1650RPM 84.7CFM/102.3CFM 35dB/38dB Flange Mount
Stock : 0

4715TS-23T-B50-AM0 electronic component of MinebeaMitsumi 4715TS-23T-B50-AM0

AC Fan Axial Ball Bearing 230V 98.84CFM/116.49CFM 46dB/50dB 119 X 119 X 38mm
Stock : 0

5910PL-05W-B50-L00 electronic component of MinebeaMitsumi 5910PL-05W-B50-L00

DC Fan Ball Bearing 24V 1A 24W 3500RPM 250CFM 62.5dB Flange Mount
Stock : 0

4715VL-07W-B86-E51 electronic component of MinebeaMitsumi 4715VL-07W-B86-E51

GIS_Unavailable
Stock : 0

More Products By Category "DC Fans"

Image Description
12537JE-12P-BA-F0 electronic component of MinebeaMitsumi 12537JE-12P-BA-F0

DC Fans DC Fan, 125x37mm, Refrigeration, 12VDC, 76.6CFM, Rib Mount, Ball Bearing, 2-Wire
Stock : 0

5920PL-05W-B60-D00 electronic component of MinebeaMitsumi 5920PL-05W-B60-D00

DC Fan Ball Bearing 24V 0.88A 21.12W 3750RPM 280CFM 62.5dB Flange Mount
Stock : 0

3106KL-04W-B59-B00 electronic component of MinebeaMitsumi 3106KL-04W-B59-B00

DC Fan Axial Ball Bearing 12V 32.8CFM 34dB 80 X 80 X 15mm
Stock : 0

11938MB-B3L-EA-00 electronic component of MinebeaMitsumi 11938MB-B3L-EA-00

AC Fan Axial Ball Bearing 230V 81CFM/88.2CFM 34dB/37dB 119 X 119 X 38mm
Stock : 0

11938KA-12M-EA-00 electronic component of MinebeaMitsumi 11938KA-12M-EA-00

NMB Technologies DC Fans
Stock : 161

2410ML-04W-B70-B00 electronic component of MinebeaMitsumi 2410ML-04W-B70-B00

DC Fan Axial Ball Bearing 12V 33.1CFM 45dB 60 X 60 X 25mm
Stock : 144

4715MS-23T-B10-A00 electronic component of MinebeaMitsumi 4715MS-23T-B10-A00

AC Fan Axial Ball Bearing 230V 45.9CFM/49.4CFM 27dB/28dB 119 X 119 X 38mm
Stock : 1

2408NL-05W-B40-P00 electronic component of MinebeaMitsumi 2408NL-05W-B40-P00

DC Fan Axial Ball Bearing 24V 15V to 27.6V 15.89CFM 29dB 60 X 60 X 20mm
Stock : 0

09232JE-12M-BA-F0 electronic component of MinebeaMitsumi 09232JE-12M-BA-F0

DC Fans DC Fan, 92x32mm, Refrigeration, 12VDC, 43.8CFM, Rib Mount, Ball Bearing, 2-Wire
Stock : 2

07530GA-12M-AA-00 electronic component of MinebeaMitsumi 07530GA-12M-AA-00

NMB Technologies Blowers
Stock : 0

Additional Infomation About Product

4715SL-05W-B70-D00 Detailed Speci cations 119 mm Frame Width: 119 mm Frame Height: 38.4 mm Frame Depth: 201 CFM Max. Air Flow: 5.69 m3 per min Max. Air Flow: 1.04 In H2O Max. Static Pressure: 260.5 Pa Max. Static Pressure: 5100 RPM Fan Speed: 62.3 dB Noise: 25 degree C 50,000 Hours L10 Life Expectancy: Ball Bearing Bearing Type: 24 V Nominal Voltage: 15 V Operating Voltage - Lower: 25.2 V Operating Voltage - Upper: 1.5 A Current: 36 W Input Power: 400 g Mass: No Tach / Locked Rotor Output: NMB Technologies Corporation - A MinebeaMitsumi Group Company - 39830 Grand River Avenue - Novi, MI 48375 info nmbtc.com DC Axial FansX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for DC Fans category: Click to view products by MinebeaMitsumi manufacturer: Other Similar products are found below : 614R AUB0612L AFB0948HH-S687 G2E085-AA05-10 4318/12T AUB0912H-F00 3412N/2ME W2G110-AM39-01 8412GLV 8412NGL- 12 6448-384 4114N/17-251 4318/2R 4412F/2D 424JMU 4414/2HH 4112 N/12GL-175 9GA0912F402 9GA0812B20011 AFB0824SHBAV1 DV5214/2NP-230 9GA0912H4021 THC1548MGDJJ 9GA0812B2001 GFB1224SHG 8500NU 9WG1212E101-E 3241.124 DC0401012V2B-3T0 ASFP14391 ASFP64371 ASFP64391 ASFP84391 ASFP92391 9A0612G402 AD5012HB-C71 AD5012MB-C71 ASFP84372 ASFP64372 31100-000440-RS ASFP14372 ASFP16371 ASFP16372 ASFP40770 ASFP42770 ASFP44770 ASFP64392 ASFP82392 ASFP84392 ASFP92371

HS Compliance

Tariff Desc

8414.59.90 FANS INCORPORATING BRUSHLESS MOTORS, having ANY of the following:
(a) DC powered;
Op. 19.10.2000 Dec. 05.01.2001 - TC 0008777
