X-On Electronics has gained recognition as a prominent supplier of FDS1102A Benchtop Oscilloscopes across the USA, India, Europe, Australia, and various other global locations. FDS1102A Benchtop Oscilloscopes are a product manufactured by OWON. We provide cost-effective solutions for Benchtop Oscilloscopes, ensuring timely deliveries around the world.

FDS1102A OWON

Name: FDS1102A
Brand: OWON
SKU: FDS1102A_OWON
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	FDS1102A
Manufacturer:	OWON
Category:	Benchtop Oscilloscopes
Description:	Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 10,4
Datasheet:
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 1983.03 ea
Line Total: USD 1983.03

Availability - 1
Ship by Thu. 10 Jul to Mon. 14 Jul

MOQ: 1 Multiples: 1
Pack Size: 1

FDS1102A More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

1

Ship by Thu. 10 Jul to Mon. 14 Jul

MOQ : 1
Multiples : 1

1 : USD 1983.03
3 : USD 1917.321

Specifications

Manufacturer

OWON OWON

Product Category

Benchtop Oscilloscopes Benchtop Oscilloscopes

Number of Channels

2 2

Bandwidth

100MHz 100MHz

Sampling Rate

1Gsps 1Gsps

Display Type

LCD TFT 10,4 LCD TFT 10,4

Input Voltage

300 V 300 V

Equipment Type

digital digital

Cable Type

EU EU

Supply Voltage

100 To 240 VAC 100 To 240 VAC

Power Consumption

30 W 30 W

Body Dimensions

421x221x115mm 421x221x115mm

Output Voltage

15 VDC 15 VDC

Output Current

3 A 3 A

Interface

USB, LAN, HDMI USB, LAN, HDMI

Output Voltage 2

15 VDC 15 VDC

Measurement Memory

100 100

Display Resolution

1024x768 1024x768

Input Impedance

1 MOhms /15pF 1 MOhms /15pF

Standard Equipment

USB cable, mains cable, users manual, test leads ( 2pcs.), oscilloscope probe (1 per channel), test lead (BNC - crocodile clips), trimmer USB cable, mains cable, users manual, test leads ( 2pcs.), oscilloscope probe (1 per channel), test lead (BNC - crocodile clips), trimmer

Additional Functions

frequency meter, function generator, multimeter, power supply frequency meter, function generator, multimeter, power supply

Measuring Instrument Features

measurements by means of cursors, mathematical functions: addition, subtraction, division, multiplication and FFT measurements by means of cursors, mathematical functions: addition, subtraction, division, multiplication and FFT

Output Current 2

3 A 3 A

Waveform Frequency Range

1µ Hz To 25 MHz (rect A ngul A r W A V eform) , 1µ Hz To 50 MHz (sinus W A V eform) , 1µ Hz To 10 MHz (pulse W A V eform) , 1µ Hz To 1 MHz (r A mp W A V eform) 1µ Hz To 25 MHz (rect A ngul A r W A V eform) , 1µ Hz To 50 MHz (sinus W A V eform) , 1µ Hz To 10 MHz (pulse W A V eform) , 1µ Hz To 1 MHz (r A mp W A V eform)

Trigger

video signal, rising - edge, falling - edge, window, pulse, runt, I2C, Nth Edge, slope, timeout, CAN, LIN, RS232, logic video signal, rising - edge, falling - edge, window, pulse, runt, I2C, Nth Edge, slope, timeout, CAN, LIN, RS232, logic

Input Coupling

AC, DC, GND AC, DC, GND

Vertical Resolution

14bit 14bit

Trigger Modes

automatic, normal, single automatic, normal, single

Manufacturer Series

FDS FDS

Measurement

AC voltage, DC voltage, frequency, capacitance, DC current, resistance, AC current AC voltage, DC voltage, frequency, capacitance, DC current, resistance, AC current

Rise Time

≤ 3.5 ns ≤ 3.5 ns

Input Sensitivity

1mV/div...10V/div 1mV/div...10V/div

Software

download from manufacturers website download from manufacturers website

Memory Record Length

10 m pts 10 m pts

Touchpad

yes yes
