X-On Electronics has gained recognition as a prominent supplier of XDS4502 Benchtop Oscilloscopes across the USA, India, Europe, Australia, and various other global locations. XDS4502 Benchtop Oscilloscopes are a product manufactured by OWON. We provide cost-effective solutions for Benchtop Oscilloscopes, ensuring timely deliveries around the world.

XDS4502 OWON

Name: XDS4502
Brand: OWON
SKU: XDS4502_OWON
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	XDS4502
Manufacturer:	OWON
Category:	Benchtop Oscilloscopes
Description:	Oscilloscope: digital; Ch: 2; 500MHz; 5Gsps; 400Mpts; LCD TFT 10,4
Datasheet:	XDS4502 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 2965.2546 ea
Line Total: USD 2965.25

Availability - 1
Ship by Thu. 10 Jul to Mon. 14 Jul

MOQ: 1 Multiples: 1
Pack Size: 1

XDS4502 More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

1

Ship by Thu. 10 Jul to Mon. 14 Jul

MOQ : 1
Multiples : 1

1 : USD 2965.2546
3 : USD 2918.685

Specifications

Manufacturer

OWON OWON

Product Category

Benchtop Oscilloscopes Benchtop Oscilloscopes

Number of Channels

2 2

Bandwidth

500MHz 500MHz

Sampling Rate

5Gsps 5Gsps

Display Type

LCD TFT 10,4 LCD TFT 10,4

Input Voltage

400 V 400 V

Equipment Type

digital digital

Cable Type

EU EU

Supply Voltage

100 To 240 VAC 100 To 240 VAC

Power Consumption

65 W 65 W

Body Dimensions

422x226x135mm 422x226x135mm

Interface

USB, LAN, VGA USB, LAN, VGA

Measurement Memory

100 100

Display Resolution

800x600 800x600

Input Impedance

1 MOhms /15pF 1 MOhms /15pF

Related Items

XDS - SOFTBAG XDS - SOFTBAG

Standard Equipment

USB cable, mains cable, users manual, oscilloscope probe (1 per channel), trimmer USB cable, mains cable, users manual, oscilloscope probe (1 per channel), trimmer

Additional Functions

frequency meter, arbitrary waveform generator, spectrum analyser frequency meter, arbitrary waveform generator, spectrum analyser

Measuring Instrument Features

measurements by means of cursors, AUTOSET function for setting display parameters (time base, gain), mathematical functions: addition, subtraction, division, multiplication and FFT, protocols analyse: I2C, CAN, SPI, RS232/UART measurements by means of cursors, AUTOSET function for setting display parameters (time base, gain), mathematical functions: addition, subtraction, division, multiplication and FFT, protocols analyse: I2C, CAN, SPI, RS232/UART

Trigger

video signal, rising - edge, falling - edge, window, pulse, runt, I2C, Nth Edge, SPI, slope, timeout, CAN, RS232, logic video signal, rising - edge, falling - edge, window, pulse, runt, I2C, Nth Edge, SPI, slope, timeout, CAN, RS232, logic

Input Coupling

AC, DC, GND AC, DC, GND

Vertical Resolution

8bit 8bit

Trigger Modes

automatic, normal, single automatic, normal, single

Manufacturer Series

XDS XDS

Rise Time

≤ 0.7 ns ≤ 0.7 ns

Input Sensitivity

1mV/div...10V/div 1mV/div...10V/div

Software

download from manufacturers website download from manufacturers website

Memory Record Length

400 m pts 400 m pts

Touchpad

yes yes
