PML711A-RO PMK

PML 711A-RO High impedance passive probe Features: 2.5 mm diameter tip TM CeramCore hybrid probe Coaxial design Interchangeable spring contact tip New IC contacting system for 0.5 to 1.27 mm pitch Read-out BNC connector PMK introduces a new universal 10:1 miniature probe for oscilloscopes with up to 500 MHz band- TM width. As all PMK probes the PML 711A features CeramCore technology. The entire probe core is made of a high quality ceramic hybrid. Pure coaxial design and laser trimmed resistors ensure highest signal fidelity along the signal path offering high bandwidth and fast risetimes for accurate impulse measurements. With a maximum input voltage of 300 V CAT II this divider is equally suitable in ser- vice and development environments. The new probe is also available with read-out BNC connector to be automatically recognised as 10:1 divider by scopes that feature a sense ring to detect probe attenuation such as Agilent, LeCroy or Tektronix. The compact design of this new probe with its 2.5 mm housing diameter at the tip provides better visibility to the DUT (device under test) in dense SMT circuits than conventional 5 mm housings. Due to the remarkably low input capacitance the signal source is only loaded by 9.5 pF. Less load to the measurement circuit can only be achieved with active probes. Especially when measuring signals with fast rise times often the probes adaption to the source signal plays an important role. Long ground leads found on most conventional adaptions bring additional inductance and resonan- ces into the setup which will result in false or inaccurate readings. The new IC contacting system consisting of five different IC adapters ranging from 1.27 to 0.5 mm pitch and the PCB adapter kit offer an ideal solution for short circuit-proof, reproducible measurements. As you would expect the probe is shipped with PMKs signature spring-loaded tips. In total there are 16 different accessories included in the scope of delivery with the new PML 711A offering adaptive solutions for almost every probing demand. Thank you for your interest in our product 2007 PMK GmbH 1PML 711A-RO Datasheet This datasheet supersedes all previously published material. Specifications that are defined typical are not guaranteed and are published as general information to the user. The instrument should have warmed up for at least 20 minutes and the environmental conditions must not exceed the spe- cified limits of the probe. Note that specifications are subject to change without notice. Electrical specifications (1) Attenuation ratio 10:1 2 % at DC Voltage coefficient 0.0025 % / V (typical) System bandwidth 500 MHz (-3 dB) System risetime 700 ps (10% 90 %) (typical) (2) Maximum rated input voltage Measurement category I: 400 V rms 1250 V transient overvoltage Measurement category II: 300 V rms CAT II Pollution degree 2 Voltage derating Typical voltage derating PML711 Measurement category I 400 300 Note that the max. input voltage rating of the probe decreases as the frequency of the applied signal 200 increases. 100 0 0,1 1 10 100 1000 Frequency MHz (1) Connect to oscilloscope with an input impedance of 1 M 1 %. (2) at 15 pF input capacitance of the measuring instrument. 2007 PMK GmbH 2 Amplitude AC rms V sinus
