R&SNGM200 POWER SUPPLY SERIES High-speed accuracy year Product Brochure Version 03.00AT A GLANCE Thanks to their high accuracy and fast load recovery time, the R&SNGM200 power supplies are perfect for challenging applications. Their two-quadrant architecture allows them to function both as a source and a sink to simulate batteries and loads. Their short recovery times enable them to handle fast load changes that occur, for example, when mobile communications devices switch from sleep mode to transmit mode. High-speed data acquisition and convenient battery simulation widen the range of applications. The single-channel R&SNGM201 and the two-channel Thanks to their fast recovery time of <30s, their mini- R&SNGM202 deliver up to 60W of output power per mum overshoot even during a demanding load change channel. The output channels are floating, galvanically iso- and fast impedance regulation, the R&SNGM200 power lated and protected against overload and short circuits. supplies are ideal for powering IoT devices and other battery -operated devices. With four measurement ranges for current and a resolu- tion of up to 6 digits when measuring voltage, current With an acquisition rate of up to 500 000 sample/s, even and power, the R&SNGM200 power supplies are perfect extremely fast variations in voltage or current can be for characterizing devices that have low power consump- captured. tion in standby mode and high current in full load opera- tion. In many cases, an additional digital multimeter is no The linear two-quadrant design of the output stages allows longer necessary. the R&SNGM200 power supply series to operate as a source and sink with minimum residual ripple and noise, ideally supporting the development of power amplifiers and MMICs. The optional battery simulation functionality provides test conditions that imitate the use of a real battery. 2
