SMD Power Inductor 104CDMCC/DS Description Metal compound molding type construction. RoHS Magnetically shielded. Low audible core noise. Suitable for large current. Halogen LWH: 11.510.34.0 mm Max. Product weight:2.2 g (Ref.) Free Moisture Sensitivity Level: 1 RoHS compliance. Halogen Free available. Dimension - mm Environmental Data 11.5 Max. 3.80.2 7.5 Operating temperature range: -55+125 (including coils self temperature rise) Storage temperature range: -55+125 Solder reflow temperature: 260 peak. Packaging Carrier tape and reel packaging. 00.15 2.00.5 500pcs per reel. 2.5 Land pattern and Schematics - mm Applications Ideally used in notebook, ultrabook, tablet PC, LCD display, Server application. 13.6 High current, POL converters. 5.4 Low profile, high current power supplies. Battery powered devices. DC/DC converters in distributed power systems. Page 1 of 5 Revised: 10-Jan-19 10.0 0.3 4.1 2.9 0.3 5.0SMD Power Inductor 104CDMCC/DS Electrical Characteristics Saturation Temperature Inductance D.C.R Current rise current Within (m) (A) (A) Part No. Stamp (H) Max.(Typ.) Max.(Typ.) (Typ.) 1 at 25 (at 25 ) 3 2 104CDMCCDS-R15MC R15 0.1520% 0.65(0.5) 60(71) 43.0 104CDMCCDS-R22MC R22 0.2220% 0.7(0.6) 59(70) 38.0 104CDMCCDS-R30MC R30 0.90(0.78) 44(52) 35.0 0.3020% 104CDMCCDS-R36MC R36 0.3620% 1.06(0.92) 44(52) 32.0 104CDMCCDS-R47MC R47 0.4720% 1.7(1.5) 43(51) 28.0 104CDMCCDS-R56MC R56 0.5620% 1.65(1.43) 34(40) 27.0 104CDMCCDS-R68MC R68 0.6820% 2.25(1.95) 33(39) 23.5 104CDMCCDS-R80MC R80 0.8020% 2.42(2.10) 27(32) 23.0 104CDMCCDS-1R0MC 1R0 1.020% 3.05(2.65) 26(31) 19.5 104CDMCCDS-1R5MC 1R5 1.520% 3.8(3.3) 24(29) 19.0 104CDMCCDS-2R2MC 2R2 7.0(6.0) 18(21) 15.0 2.220% 104CDMCCDS-3R3MC 3R3 3.320% 12.0(10.0) 16(18) 12.0 104CDMCCDS-4R7MC 4R7 4.720% 14.8(12.8) 14(16) 11.0 104CDMCCDS-6R8MC 6R8 6.820% 25.0(22.0) 11.0(12.5) 8.5 104CDMCCDS-8R2MC 8R2 8.220% 27.0(25.0) 10.0(12.0) 8.3 104CDMCCDS-100MC 100 1020% 30.0(27.0) 8.5(10.0) 7.5 104CDMCCDS-150MC 150 1520% 45.0(40.0) 6.1(7.2) 6.3 104CDMCCDS-220MC 220 2220% 66.0(58.0) 5.5(6.5) 5.0 104CDMCCDS-330MC 330 92.0(85.0) 4.4(5.2) 4.1 3320% 104CDMCCDS-470MC 470 4720% 145(130) 3.6(4.3) 3.2 104CDMCCDS-680MC 680 6820% 195(178) 3.4(4.0) 2.5 1 Measuring frequency Inductance at 100kHz ,1.0V 2 Saturation current: The value of DC current when the inductance is over 30% of its initial value. (at 25 ) 3 Temperature rise current: The actual value of DC current when temperature of coil rise is T=40(Ta=25) Page 2 of 5 Revised: 10-Jan-19
