405264508 TE Connectivity

5.0 mm Power Key Connectors Standard Density .197 5.00 Centerline Soft Shell Pin and Socket Connectors AMP 5.0 mm Power Key Connectors (5.0 PKC) (Wire-to-Board) Product Facts Compact design with 19.4 mm mated height Power circuit connector with 5.0 mm contact centerline Wire-to-board connectors consisting of plug housings for wires and PCB header assemblies With a clear clicking sound, contact insertions can be made easier. The double lock plate provides for complete loading of contacts Locking levers are surrounded by walls, which protect levers and prevent tangling with wires Connector is designed to release bubbles created by the process of potting (PC board coating) 5.0 mm Power Key Performance Characteristics Technical Documents Housing lances also help Connectors are for power 1 Voltage Rating300 VAC Product Specification prevent tangling of wired circuits of home appliances, 2 Current Rating10A max. 108-5699 contacts especially targeting gas Operating Temperature Application Specification appliances. The connector Recognized under the -30C ~ +105C 114-5292 features four kinds of keying Component Program Applicable Wire24-16 AWG per housing. of Underwriters R Applicable PC Board Thickness Laboratories Inc., Only color-coding of hous- 1.6 mm File No. E28476 ings limited the efficiency of blind mating where you Certified by Canadian R 1 Excludes header tyne round could not see connectors. Standards Association, space. Usable for 150 VAC However, the new keying applications when the round File No. LR7189 mechanism not only dimensions are 3 mm or less. improves assembly 2 Specified values vary according to efficiency but also helps the number of contacts and the prevent mismating. wire used. The 10 A maximum value applies to 16 AWG wire Part numbers involved used with 2 contacts. can be reduced so that purchasing and stock level control can be made simpler. 135 Catalog 82181 Dimensions are in inches and Dimensions are shown for USA: 1-800-522-6752 South America: 55-11-2103-6000 Revised 4-08 millimeters unless otherwise reference purposes only. Canada: 1-905-470-4425 Hong Kong: 852-2735-1628 specified. Values in brackets Specifications subject Mexico: 01-800-733-8926 Japan: 81-44-844-8013 www.tycoelectronics.com are metric equivalents. to change. C. America: 52-55-1106-0803 UK: 44-8706-080-208Soft Shell Pin and Socket Connectors AMP 5.0 mm Power Key Connectors (5.0 PKC) (Wire-to-Board) (Continued) Quick Reference Chart for Mating Part Numbers Applicable Plug Housing Mating Header Assy. No. of Pos. Double Lock Plate Part Number Type of Keying/Color Part Number Part Number Type A/Natural 1376388-1 1376394-1 1376382-1 Type B/Red 1-1376388-2 1376394-1 1-1376382-2 2 Type C/Blue 2-1376388-3 1376294-1 2-1376382-3 Type D/Yellow 3-1376388-4 1376394-1 3-1376382-4 Type A/Natural 1376389-1 1376395-1 1376383-1 1376421-1 Type B/Red 1-1376389-2 1376395-1 1-1376383-2 1-1376421-2 3 Type C/Blue 2-1376389-3 1376395-1 2-1376383-3 2-1376421-3 Type D/Yellow 3-1376389-4 1376395-1 3-1376383-4 3-1376421-4 Type A/Natural 1376390-1 1376396-1 1376384-1 Type B/Red 1-1376390-2 1376396-1 1-1376384-2 4 Type C/Blue 2-1376390-3 1376396-1 2-1376384-3 Type D/Yellow 3-1376390-4 1376396-1 3-1376384-4 Type A/Natural 1376391-1 1376397-1 1376385-1 Type B/Red 1-1376391-2 1376397-1 1-1376385-2 6 Type C/Blue 2-1376391-3 1376397-1 2-1376385-3 Type D/Yellow 3-1376391-4 1376397-1 3-1376385-4 2 Row Type A/Natural 1376392-1 1376394-1 1376386-1 Type B/Red 1-1376392-2 1376394-1 1-1376386-2 4 Type C/Blue 2-1376392-3 1376394-1 2-1376386-3 Type D/Yellow 3-1376392-4 1376394-1 3-1376386-4 Type A/Natural 1376393-1 1376395-1 1376387-1 Type B/Red 1-1376393-2 1376395-1 1-1376387-2 6 Type C/Blue 2-1376393-3 1376395-1 2-1376387-3 Type D/Yellow 3-1376393-4 1376395-1 3-1376387-4 *Included in Header Assy. line are Tube Stick version. Refer to the appropriate description in the catalog. Note: All part numbers are RoHS Compliant. Note: Dimensions shown are metric. 136 Catalog 82181 Dimensions are in inches and Dimensions are shown for USA: 1-800-522-6752 South America: 55-11-2103-6000 Revised 4-08 millimeters unless otherwise reference purposes only. Canada: 1-905-470-4425 Hong Kong: 852-2735-1628 specified. Values in brackets Specifications subject Mexico: 01-800-733-8926 Japan: 81-44-844-8013 www.tycoelectronics.com are metric equivalents. to change. C. America: 52-55-1106-0803 UK: 44-8706-080-208 5.0 mm Power Key Connectors .197 5.00 Centerline Standard Density
