X-On Electronics has gained recognition as a prominent supplier of MSO2202-S Benchtop Oscilloscopes across the USA, India, Europe, Australia, and various other global locations. MSO2202-S Benchtop Oscilloscopes are a product manufactured by Uni-T. We provide cost-effective solutions for Benchtop Oscilloscopes, ensuring timely deliveries around the world.

MSO2202-S Uni-T

Name: MSO2202-S
Brand: Uni-T
SKU: MSO2202S_Uni-T
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	MSO2202-S
Manufacturer:	Uni-T
Category:	Benchtop Oscilloscopes
Description:	Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8
Datasheet:	MSO2202-S Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 1664.481 ea
Line Total: USD 1664.48

Availability - 1
Ship by Thu. 10 Jul to Mon. 14 Jul

MOQ: 1 Multiples: 1
Pack Size: 1

MSO2202-S More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

1

Ship by Thu. 10 Jul to Mon. 14 Jul

MOQ : 1
Multiples : 1

1 : USD 1664.481

Specifications

Manufacturer

Uni-T Uni-T

Product Category

Benchtop Oscilloscopes Benchtop Oscilloscopes

Number of Channels

2 2

Bandwidth

200MHz 200MHz

Sampling Rate

2 Gs/s 2 Gs/s

Display Type

LCD TFT 8 LCD TFT 8

Equipment Type

digital digital

Supply Voltage

100 To 240 VAC 100 To 240 VAC

Interface

LAN, VGA, USB Host, USB device, AUX LAN, VGA, USB Host, USB device, AUX

Display Resolution

800x480 800x480

Input Impedance

1 MOhms /16pF 1 MOhms /16pF

Dimensions

370x185x115mm 370x185x115mm

Related Items

MSO/UPO2000 - AUTO, MSO/UPO2000 - BND, MSO/UPO2000 - CAN, MSO/UPO2000 - CANF, MSO/UPO2000 - COM, MSO/UPO2000 - EMBD, MSO/UPO2000 - FR, MSO/UPO2000 - I2C, MSO/UPO2000 - LIN, MSO/UPO2000 - SPI MSO/UPO2000 - AUTO, MSO/UPO2000 - BND, MSO/UPO2000 - CAN, MSO/UPO2000 - CANF, MSO/UPO2000 - COM, MSO/UPO2000 - EMBD, MSO/UPO2000 - FR, MSO/UPO2000 - I2C, MSO/UPO2000 - LIN, MSO/UPO2000 - SPI

Standard Equipment

USB cable, mains cable, BNC cable, test probe x2 USB cable, mains cable, BNC cable, test probe x2

Measuring Instrument Features

mathematical functions: addition, subtraction, division, multiplication and FFT, automatic measurement of many parameters, split screen function, arbitrary waveform generator mathematical functions: addition, subtraction, division, multiplication and FFT, automatic measurement of many parameters, split screen function, arbitrary waveform generator

Trigger

video signal, rising - edge, falling - edge, impulse width, runt, with delay, runt, pattern, Nth Edge, slope video signal, rising - edge, falling - edge, impulse width, runt, with delay, runt, pattern, Nth Edge, slope

Input Coupling

AC, DC, GND AC, DC, GND

Vertical Resolution

8bit 8bit

Rise Time

≤ 1.8 ns ≤ 1.8 ns

Input Sensitivity

500µV/div...20V/div 500µV/div...20V/div

Time Base

1n To 1ks/div 1n To 1ks/div

Memory Record Length

56 m pts 56 m pts

Notes:- Show Stocked Products With Similar Attributes.

MSO2202-S Alternative Parts

We are delighted to provide the MSO2202-S from our Benchtop Oscilloscopes category, at competitive rates not only in the United States, Australia, and India, but also across Europe and beyond. A long established and extensive electronic component distribution network has enhanced our global reach and dependability, ensuring cost savings through prompt deliveries worldwide. Client satisfaction is at the heart of our business, where every component counts and every customer matters. Our technical service team is ready to assist you. From product selection to after-sales support, we strive to deliver a seamless and satisfying experience. Are you ready to experience the best in electronic component distribution? Contact X-ON Electronics today and discover why X-On are a preferred choice for the MSO2202-S and other electronic components in the Benchtop Oscilloscopes category and beyond.
