UPO2104 Uni-T

Name: UPO2104
Brand: Uni-T
SKU: UPO2104_Uni-T
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only, See Product Specifications

X-On Electronics has gained recognition as a prominent supplier of UPO2104 Benchtop Oscilloscopes across the USA, India, Europe, Australia, and various other global locations. UPO2104 Benchtop Oscilloscopes are a product manufactured by Uni-T. We provide cost-effective solutions for Benchtop Oscilloscopes, ensuring timely deliveries around the world.

Part No.

UPO2104

Manufacturer:

Uni-T

Category:

Benchtop Oscilloscopes

Description:

Oscilloscope: digital; Ch: 4; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8

Datasheet:

UPO2104 Datasheet (PDF)

Shipping Charges:

Click here for details

Request our AI to suggest items that go with UPO2104 (Current search time: 5 ± 2 seconds)

Request our AI to suggest equivalents. (Current search time: 15 ± 4 seconds)

Price (USD)

1: USD 1209.3984 ea
Line Total: USD 1209.4

Availability : 1

Ship by Fri. 19 Jun to Tue. 23 Jun

Qty Unit Price
1 $ 1209.3984

UPO2104 More Buying Options & Price Grid(s)

Please wait...
Availability
Price (USD)
Buy Price
Quantity
Availability1
Ship by Fri. 19 Jun to Tue. 23 Jun
MOQ : 1
Multiples : 1
Qty Unit Price
1 $ 1209.3984

Specifications

Manufacturer
Uni-TUni-T

Product Category
Benchtop OscilloscopesBenchtop Oscilloscopes

Number of Channels
44

Bandwidth
100MHz100MHz

Sampling Rate
2 Gs/s2 Gs/s

Display Type
LCD TFT 8LCD TFT 8

Equipment Type
digitaldigital

Supply Voltage
100 To 240 VAC100 To 240 VAC

Interface
LAN, VGA, USB Host, USB device, AUXLAN, VGA, USB Host, USB device, AUX

Display Resolution
800x480800x480

Input Impedance
1 MOhms /16pF1 MOhms /16pF

Dimensions
370x185x115mm370x185x115mm

Related Items
MSO/UPO2000 - AUTO, MSO/UPO2000 - BND, MSO/UPO2000 - CAN, MSO/UPO2000 - CANF, MSO/UPO2000 - COM, MSO/UPO2000 - EMBD, MSO/UPO2000 - FR, MSO/UPO2000 - I2C, MSO/UPO2000 - LIN, MSO/UPO2000 - SPIMSO/UPO2000 - AUTO, MSO/UPO2000 - BND, MSO/UPO2000 - CAN, MSO/UPO2000 - CANF, MSO/UPO2000 - COM, MSO/UPO2000 - EMBD, MSO/UPO2000 - FR, MSO/UPO2000 - I2C, MSO/UPO2000 - LIN, MSO/UPO2000 - SPI

Standard Equipment
USB cable, mains cable, BNC cable, test probe x2USB cable, mains cable, BNC cable, test probe x2

Measuring Instrument Features
mathematical functions: addition, subtraction, division, multiplication and FFT, automatic measurement of many parameters, split screen functionmathematical functions: addition, subtraction, division, multiplication and FFT, automatic measurement of many parameters, split screen function

Trigger
video signal, rising - edge, falling - edge, impulse width, runt, with delay, runt, pattern, Nth Edge, slopevideo signal, rising - edge, falling - edge, impulse width, runt, with delay, runt, pattern, Nth Edge, slope

Input Coupling
AC, DC, GNDAC, DC, GND

Vertical Resolution
8bit8bit

Rise Time
≤ 3.5 ns≤ 3.5 ns

Input Sensitivity
500µV/div...20V/div500µV/div...20V/div

Time Base
2n To 1ks/div2n To 1ks/div

Memory Record Length
56 m pts56 m pts
