X-On Electronics has gained recognition as a prominent supplier of MSO2204-S Benchtop Oscilloscopes across the USA, India, Europe, Australia, and various other global locations. MSO2204-S Benchtop Oscilloscopes are a product manufactured by Uni-T. We provide cost-effective solutions for Benchtop Oscilloscopes, ensuring timely deliveries around the world.

MSO2204-S Uni-T

Name: MSO2204-S
Brand: Uni-T
SKU: MSO2204S_Uni-T
Availability: OutOfStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	MSO2204-S
Manufacturer:	Uni-T
Category:	Benchtop Oscilloscopes
Description:	Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8
Datasheet:	MSO2204-S Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 1780.6992 ea
Line Total: USD 1780.7

Availability - 0

MOQ: 1 Multiples: 1
Pack Size: 1

MSO2204-S More Buying Options & Price Grid(s)

Availability	Price	Buy Price	Quantity
0 Ship by Thu. 10 Jul to Mon. 14 Jul MOQ : 1 Multiples : 1	1 : USD 1780.6992

Specifications

Manufacturer Uni-T Uni-T
Product Category Benchtop Oscilloscopes Benchtop Oscilloscopes
Number of Channels 4 4
Bandwidth 200MHz 200MHz
Sampling Rate 2 Gs/s 2 Gs/s
Display Type LCD TFT 8 LCD TFT 8
Equipment Type digital digital
Supply Voltage 100 To 240 VAC 100 To 240 VAC
Interface LAN, VGA, USB Host, USB device, AUX LAN, VGA, USB Host, USB device, AUX
Display Resolution 800x480 800x480
Input Impedance 1 MOhms /16pF 1 MOhms /16pF
Dimensions 370x185x115mm 370x185x115mm
Related Items MSO/UPO2000 - AUTO, MSO/UPO2000 - BND, MSO/UPO2000 - CAN, MSO/UPO2000 - CANF, MSO/UPO2000 - COM, MSO/UPO2000 - EMBD, MSO/UPO2000 - FR, MSO/UPO2000 - I2C, MSO/UPO2000 - LIN, MSO/UPO2000 - SPI MSO/UPO2000 - AUTO, MSO/UPO2000 - BND, MSO/UPO2000 - CAN, MSO/UPO2000 - CANF, MSO/UPO2000 - COM, MSO/UPO2000 - EMBD, MSO/UPO2000 - FR, MSO/UPO2000 - I2C, MSO/UPO2000 - LIN, MSO/UPO2000 - SPI
Standard Equipment USB cable, mains cable, BNC cable, test probe x2 USB cable, mains cable, BNC cable, test probe x2
Measuring Instrument Features mathematical functions: addition, subtraction, division, multiplication and FFT, automatic measurement of many parameters, split screen function, arbitrary waveform generator mathematical functions: addition, subtraction, division, multiplication and FFT, automatic measurement of many parameters, split screen function, arbitrary waveform generator
Trigger video signal, rising - edge, falling - edge, impulse width, runt, with delay, runt, pattern, Nth Edge, slope video signal, rising - edge, falling - edge, impulse width, runt, with delay, runt, pattern, Nth Edge, slope
Input Coupling AC, DC, GND AC, DC, GND
Vertical Resolution 8bit 8bit
Rise Time ≤ 1.8 ns ≤ 1.8 ns
Input Sensitivity 500µV/div...20V/div 500µV/div...20V/div
Time Base 1n To 1ks/div 1n To 1ks/div
Memory Record Length 56 m pts 56 m pts

We are delighted to provide the MSO2204-S from our Benchtop Oscilloscopes category, at competitive rates not only in the United States, Australia, and India, but also across Europe and beyond. A long established and extensive electronic component distribution network has enhanced our global reach and dependability, ensuring cost savings through prompt deliveries worldwide. Client satisfaction is at the heart of our business, where every component counts and every customer matters. Our technical service team is ready to assist you. From product selection to after-sales support, we strive to deliver a seamless and satisfying experience. Are you ready to experience the best in electronic component distribution? Contact X-ON Electronics today and discover why X-On are a preferred choice for the MSO2204-S and other electronic components in the Benchtop Oscilloscopes category and beyond.

Uni-T may also be referenced as

Uni-Trend Tech
