672D686F060DM5J Vishay

672D www.vishay.com Vishay Sprague Aluminum Capacitors +105 C, Miniature, Radial Lead FEATURES Original SMPS output capacitors Minimal ESR change Available High ripple current capability Material categorization: for definitions of compliance please see www.vishay.com/doc 99912 RIPPLE CURRENT MULTIPLIERS TEMPERATURE QUICK REFERENCE DATA AMBIENT MULTIPLIERS TEMPERATURE DESCRIPTION VALUE +105 C 0.5 Nominal case size 0.394 x 0.472 10.0 x 12.0 D x L in inches mm to 0.709 x 1.575 18.0 x 40.0 +85 C 1.0 Operating temperature -55 C to +105 C +75 C 1.25 Rated capacitance range, C 4.7 F to 3300 F R FREQUENCY (Hz) Tolerance on C -10 %, +50 % R WV 50 TO 60 100 TO 120 300 TO 400 1K TO 19K DC Rated voltage range, U 6.3 WV to 250 WV R DC DC 0 to 75 0.60 0.70 0.75 0.80 2 and 3 radial leads and axial 76 to 100 0.40 0.55 0.70 0.80 Termination mount. 101 to 250 0.25 0.35 0.45 0.65 4000 h at +105 C ( 13.0 mm dia.): 3000 h at +105 C (10.0 mm dia.): CAP 20 % from initial Life validation test LOW TEMPERATURE PERFORMANCE measurement. -55 C +25 C ESR 1.15 x initial specified limit. CAPACITANCE RATIO C / C MINIMUM AT 120 Hz DCL initial specified limit. VOLTAGE MULTIPLIER MAXIMUM 500 h: CAP 10 % from initial CAPACITANCE 6.3 V to 100 V 0.75 measurement. CHANGE ESR 1.15 x initial specified limit. 150 V to 250 V 0.70 Shelf life at 105 C DCL 2 x initial specified limit, VOLTAGE MULTIPLIER (6.3 WV to 100 WV ) MAXIMUM DC DC IMPEDANCE 6.3 V to 100 V 2.5 3 x initial specified limit, CHANGE (150 WV to 250 WV ). DC DC 150 V to 250 V 2.0 I = 0.03 CV ESL (TYPICAL VALUES AT 1 MHz TO 10 MHz) (6.3 V to 100 V ) DC DC DC leakage current NOMINAL 0.394 0.512 0.630 0.709 I = 0.01 CV (after 2 min charge) DIAMETER 10.0 13.0 16.0 18.0 (150 V to 250 V ) DC DC I in A, C in F, V in Volts TYPICAL ESL (nH) 4.0 7.0 10.0 12.0 Revision: 18-Jul-16 Document Number: 42054 1 For technical questions, contact: aluminumcaps4 vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 672D www.vishay.com Vishay Sprague BULK SPECIFICATIONS in millimeters TERMINAL CODE C TERMINAL CODE D 9.5 min. 20 min. S L S L W W + + D D - - 15 min. Sleeve Sleeve 7.1 min. (1) (2) TERMINAL CODE J TERMINAL CODE O 9.5 1.6 25 min. 25 min. L S S L W W T + + NC D D - NC - 5.0 1.6 25 min. Sleeve Sleeve Third lead may fall within 20 of C L 7.1 1.6 Notes + Positive terminal - Negative terminal NC No charge potential (1) Available for 12.5 mm, 16 mm, and 18 mm diameter units (2) Available for 12.5 mm, 16 mm, and 18 mm diameter units with epoxy end-seal DIMENSIONS in inches millimeters NOMINAL STYLES 2 AND 4 STYLES 3 AND 5 LEAD SPACING LEAD DIAMETER CASE S 0.024 T 0.020 CODE D L D (max.) L (max.) D (max.) L (max.) NOMINAL AWG 0.60 0.50 CC 0.394 10.0 0.512 13.0 0.413 10.5 0.563 14.3 0.413 10.5 0.630 16.0 0.197 5.0 n/a 0.025 0.63 22 CD 0.394 10.0 0.630 16.0 0.413 10.5 0.669 17.0 0.413 10.5 0.740 18.8 0.197 5.0 n/a 0.025 0.63 22 CG 0.394 10.0 0.787 20.0 0.413 10.5 0.846 21.5 0.413 10.5 0.906 23.0 0.197 5.0 n/a 0.025 0.63 22 DG 0.492 12.5 0.787 20.0 0.512 13.0 0.846 21.5 0.512 13.0 0.906 23.0 0.197 5.0 0.098 2.5 0.032 0.81 20 DK 0.492 12.5 0.984 25.0 0.512 13.0 1.043 26.5 0.512 13.0 1.142 29.0 0.197 5.0 0.098 2.5 0.032 0.81 20 DM 0.492 12.5 1.043 26.5 0.512 13.0 1.102 28.0 0.512 13.0 1.161 29.5 0.197 5.0 0.098 2.5 0.032 0.81 20 DT 0.492 12.5 1.319 33.5 0.512 13.0 1.346 34.2 0.512 13.0 1.417 36.0 0.197 5.0 0.098 2.5 0.032 0.81 20 DS 0.492 12.5 1.673 42.5 0.512 13.0 1.720 43.7 0.512 13.0 1.791 45.5 0.197 5.0 0.098 2.5 0.032 0.81 20 EK 0.630 16.0 0.984 25.0 0.650 16.5 1.031 26.2 0.650 16.5 1.098 27.9 0.295 7.5 0.150 3.8 0.032 0.81 20 EN 0.630 16.0 1.260 32.0 0.650 16.5 1.319 33.5 0.650 16.5 1.417 36.0 0.295 7.5 0.150 3.8 0.032 0.81 20 ER 0.630 16.0 1.417 36.0 0.650 16.5 1.476 37.5 0.650 16.5 1.575 40.0 0.295 7.5 0.150 3.8 0.032 0.81 20 ET 0.630 16.0 1.319 33.5 0.650 16.5 1.347 34.2 0.650 16.5 1.417 36.0 0.295 7.5 0.150 3.8 0.032 0.81 20 EU 0.630 16.0 1.575 40.0 0.650 16.5 1.642 41.7 0.650 16.5 1.669 42.4 0.295 7.5 0.150 3.8 0.032 0.81 20 FR 0.709 18.0 1.417 36.0 0.728 18.5 1.476 37.5 0.728 18.5 1.575 40.0 0.295 7.5 0.150 3.8 0.032 0.81 20 FV 0.709 18.0 1.575 40.0 0.728 18.5 1.653 42.0 0.728 18.5 1.693 43.0 0.295 7.5 0.150 3.8 0.032 0.81 20 Revision: 18-Jul-16 Document Number: 42054 2 For technical questions, contact: aluminumcaps4 vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
