MAL213630221E3 Vishay

136 RVI www.vishay.com Vishay BCcomponents Aluminum Electrolytic Capacitors Radial Very Low Impedance FEATURES Very low impedance and low ESR Very long useful life: 4000 h to 10 000 h at 105 C, very high reliability Excellent ripple current capability Polarized aluminum electrolytic capacitors, non-solid electrolyte Radial leads, cylindrical aluminum case with pressur e relief, insulated with a blue sleeve Charge and discharge proof Material categorization: for definitions of compliance 140 RTM 125 C please see www.vishay.com/doc 99912 higher APPLICATIONS temperature Power supplies (SMPS, DC/DC converters) for genera l 150 RMI 136 RVI miniaturized industrial, EDP, audio-video, and telecommunications Smoothing, filtering, buffering higher CV/volume MARKING The capacitors are marked (where possible) with th e 048 RML miniaturized 148 RUS following information: Fig. 1 Rated capacitance value (in F) Tolerance on rated capacitance, code letter in accordanc e QUICK REFERENCE DATA with IEC 60062 (M for 20 %) DESCRIPTION VALUE Rated voltage (in V) Nominal case sizes ( D x L in mm) 10 x 12 to 18 x 35 Rated capacitance range, C 22 F to 10 000 F Date code, in accordance with IEC 60062 R Tolerance on C 20 % R Code indicating factory of origin Rated voltage range, C 10 V to 100 V R Name of manufacturer Category temperature range -55 C to +105 C Upper category temperature (105 C) 3000 h to 5000 h Endurance test at 105 C (dependent on case size) Negative terminal identification 4000 h to 10 000 h Useful life at 105 C Series number (136) (dependent on case size) Useful life at 40 C, 200 000 h to 500 000 h 1.8 x I applied (dependent on case size) R Shelf life at 0 V, 105 C 1000 h Based on sectional specification IEC 60384-4 / EN130300 Climatic category IEC 60 068 55 / 105 / 56 Revision: 16-Mar-2021 Document Number: 28321 1 For technical questions, contact: aluminumcaps1 vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 136 RVI www.vishay.com Vishay BCcomponents SELECTION CHART FOR C , U , AND RELEVANT NOMINAL CASE SIZES ( D x L in mm) R R U (V) R C R (F) 10 16 25 35 50 63 100 22 - - - - - - 10 x 12 33 - - - - - - 10 x 12 47 - - - - - 10 x 12 10 x 16 56 - - - - - 10 x 12 - 68 - - - - - 10 x 16 10 x 20 82 - - - - 10 x 12 - - 100 - - - - 10 x 12 10 x 16 12.5 x 20 120 - - - 10 x 12 10 x 16 10 x 20 - 150 - - - 10 x 12 10 x 20 - 16 x 20 180 - - 10 x 12 - 10 x 20 - - 220 - - 10 x 12 10 x 16 - 12.5 x 20 16 x 25 270 - 10 x 12 - - - 12.5 x 25 - 330 - 10 x 12 10 x 16 10 x 20 12.5 x 20 16 x 20 16 x 31 390 10 x 12 - - - - - - 10 x 12 10 x 16 10 x 20 12.5 x 20 12.5 x 25 16 x 25 16 x 35 470 -- --- - 18 x 31 560 - - - 12.5 x 20 - - - 10 x 16 10 x 20 - 12.5 x 25 16 x 20 16 x 31 18 x 35 680 -- --- 18 x 25 - 820 - - 12.5 x 20 - 16 x 25 16 x 35 - 10 x 20 12.5 x 20 12.5 x 25 16 x 20 16 x 31 18 x 31 - 1000 -- -- 18 x 20 -- 1200 - 12.5 x 20 - 16 x 25 16 x 35 - - 1500 12.5 x 20 12.5 x 25 16 x 20 16 x 25 18 x 31 18 x 35 - 1800 12.5 x 20 - 16 x 25 16 x 31 - - - 12.5 x 25 16 x 20 16 x 31 16 x 35 18 x 35 - - 2200 - - 18 x 20 18 x 31 - - - 2700 - 16 x 25 16 x 31 - - - - 16 x 20 16 x 25 16 x 35 18 x 35 - - - 3300 -- 18 x 31 -- -- 3900 16 x 25 16 x 31 - - - - - 16 x 31 16 x 35 18 x 35 - - - - 4700 - 18 x 31 --- -- 16 x 31 - --- -- 5600 18 x 25 - --- -- 16 x 35 18 x 35 - - - - - 6800 18 x 31 - --- -- 10 000 18 x 35 - - - - - - Revision: 16-Mar-2021 Document Number: 28321 2 For technical questions, contact: aluminumcaps1 vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
