SiHG24N65E www.vishay.com Vishay Siliconix E Series Power MOSFET FEATURES PRODUCT SUMMARY Low figure-of-merit (FOM) R x Q on g V (V) at T max. 700 DS J Low input capacitance (C ) iss R max. at 25 C ()V = 10 V 0.145 DS(on) GS Reduced switching and conduction losses Q max. (nC) 122 g Ultra low gate charge (Q ) g Q (nC) 21 gs Available Avalanche energy rated (UIS) Q (nC) 37 gd Material categorization: for definitions of compliance Configuration Single please see www.vishay.com/doc 99912 APPLICATIONS D TO-247AC Server and telecom power supplies Switch mode power supplies (SMPS) Power factor correction power supplies (PFC) Lighting G - High-intensity discharge (HID) S - Fluorescent ballast lighting D G Industrial S - Welding N-Channel MOSFET - Induction heating - Motor drives - Battery chargers - Renewable energy - Solar (PV inverters) ORDERING INFORMATION Package TO-247AC Lead (Pb)-free SiHG24N65E-E3 SiHG24N65E-GE3 Lead (Pb)-free and Halogen-free ABSOLUTE MAXIMUM RATINGS (T = 25 C, unless otherwise noted) C PARAMETER SYMBOLLIMITUNIT Drain-Source Voltage V 650 DS V Gate-Source Voltage V 30 GS T = 25 C 24 C Continuous Drain Current (T = 150 C) V at 10 V I J GS D T = 100 C 16 A C a Pulsed Drain Current I 70 DM Linear Derating Factor 2W/C b Single Pulse Avalanche Energy E 508 mJ AS Maximum Power Dissipation P 250 W D Operating Junction and Storage Temperature Range T , T -55 to +150 C J stg Drain-Source Voltage Slope T = 125 C 37 J dV/dt V/ns d Reverse Diode dV/dt 11 c Soldering Recommendations (Peak Temperature) for 10 s 300 C Notes a. Repetitive rating pulse width limited by maximum junction temperature. b. V = 50 V, starting T = 25 C, L = 28.2 mH, R = 25 , I = 6 A. DD J g AS c. 1.6 mm from case. d. I I , dI/dt = 100 A/s, starting T = 25 C. SD D J S15-0291-Rev. G, 23-Feb-15 Document Number: 91476 1 For technical questions, contact: hvm vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000SiHG24N65E www.vishay.com Vishay Siliconix THERMAL RESISTANCE RATINGS PARAMETER SYMBOLTYP. MAX. UNIT Maximum Junction-to-Ambient R -62 thJA C/W Maximum Junction-to-Case (Drain) -0.5 R thJC SPECIFICATIONS (T = 25 C, unless otherwise noted) J PARAMETER SYMBOLTEST CONDITIONS MIN.TYP.MAX.UNIT Static Drain-Source Breakdown Voltage V V = 0 V, I = 250 A 650 - - V DS GS D V /T -0.72 - V Temperature Coefficient Reference to 25 C, I = 250 A V/C DS DS J D Gate-Source Threshold Voltage (N) V V = V , I = 250 A 2 - 4 V GS(th) DS GS D V = 20 V - - 100 nA GS Gate-Source Leakage I GSS V = 30 V - - 1 A GS V = 650 V, V = 0 V - - 1 DS GS Zero Gate Voltage Drain Current I A DSS V = 520 V, V = 0 V, T = 125 C - - 10 DS GS J Drain-Source On-State Resistance R V = 10 V I = 12 A - 0.120 0.145 DS(on) GS D Forward Transconductance g V = 8 V, I = 5 A - 7.1 - S fs DS D Dynamic Input Capacitance C - 2740 - pF iss V = 0 V, GS Output Capacitance C -V = 100 V, 122- oss DS f = 1 MHz Reverse Transfer Capacitance C -4- rss Effective Output Capacitance, Energy C -93 - a o(er) Related V = 0 V to 520 V, V = 0 V DS GS Effective Output Capacitance, Time C - 352 - o(tr) b Related Total Gate Charge Q -81 122 g Gate-Source Charge Q -2V = 10 V I = 12 A, V = 520 V1- nC gs GS D DS Gate-Drain Charge Q -37- gd Turn-On Delay Time t -24 48 d(on) Rise Time t -84 126 r V = 520 V, I = 12 A, DD D ns Turn-Off Delay Time t -70105 V = 10 V, R = 9.1 d(off) GS g Fall Time t -69104 f Gate Input Resistance R f = 1 MHz, open drain - 0.68 - g Drain-Source Body Diode Characteristics MOSFET symbol D Continuous Source-Drain Diode Current I -- 24 S showing the A G integral reverse Pulsed Diode Forward Current I -- 70 S SM p - n junction diode Diode Forward Voltage V T = 25 C, I = 12 A, V = 0 V - - 1.2 V SD J S GS Reverse Recovery Time t - 433 - ns rr T = 25 C, I = I = 12 A, J F S Reverse Recovery Charge Q -7.3 - C rr dI/dt = 100 A/s, V = 25 V R Reverse Recovery Current I -28 - A RRM Notes a. C is a fixed capacitance that gives the same energy as C while V is rising from 0 % to 80 % V . oss(er) oss DS DSS b. C is a fixed capacitance that gives the same charging time as C while V is rising from 0 % to 80 % V . oss(tr) oss DS DSS S15-0291-Rev. G, 23-Feb-15 Document Number: 91476 2 For technical questions, contact: hvm vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
