Data sheet... Weidmller Interface GmbH & Co. KG H1,5/14D SW BD Klingenbergstrae 16 D-32758 Detmold Germany Fon: +49 5231 14-0 Fax: +49 5231 14-292083 www.weidmueller.com Linked of wire-end ferrule strips (50 pcs.) Weidmller colour code DIN colour code General ordering data Order No. 9004350000 Type H1,5/14D SW BD Version Wire end ferrule, 1.5 mm, 8 mm, Colour code: DIN, Black GTIN (EAN) 4008190005474 Qty. 500 pc(s). Creation date May 8, 2013 3:39:03 PM CEST Catalogue status 12.03.2013 / We reserve the right to make technical changes. 1Data sheet... Weidmller Interface GmbH & Co. KG H1,5/14D SW BD Klingenbergstrae 16 D-32758 Detmold Germany Fon: +49 5231 14-0 Fax: +49 5231 14-292083 www.weidmueller.com Technical data Dimensions and weights Length 14 mm Net weight 0.118 g Product data Conductor cross-section Wire connection cross section AWG, 1.5 mm max. AWG 16 Contact surface length (L2) 8 mm Contact surface diameter (D1) 1.7 mm Collar diameter (D2) 3.2 mm Metal sleeve thickness (S1) 0.15 mm Plastic collar thickness (S2) 0.25 mm Classifications ETIM 2.0 EC000005 ETIM 3.0 EC000005 UNSPSC 31-16-31-02 eClass 4.1 27-06-07-01 eClass 5.1 27-40-02-01 eClass 6.2 27-40-02-01 eClass 7.1 27-40-02-01 Product information Description of article Wire-end ferrule Approvals Approvals ROHS Conform Creation date May 8, 2013 3:39:03 PM CEST Catalogue status 12.03.2013 / We reserve the right to make technical changes. 2
