Introduction
The Schottky Diodes & Rectifiers S36 by Yangjie are high-performance Semiconductors designed for low forward voltage drop, fast recovery times, and excellent energy efficiency. As part of the Discrete Semiconductors category, these diodes are ideal for applications such as power rectification, DC-DC converters, and reverse polarity protection.
Engineered for reliability and stable performance, S36 Schottky Diodes & Rectifiers are widely used in consumer electronics, power supplies, and industrial circuits. In this blog, we explore their technical details, key features, applications, and why www.xonelec.com is the ideal global source for these components.
Technical Specifications of S36
-
Manufacturer: Yangjie
-
Part Number: S36
-
Type: Schottky Diodes & Rectifiers
-
Reverse Voltage (VR): 60 V
-
Forward Current (IF): 3 A
-
Forward Voltage Drop (VF): = 0.85 V
-
Package: DO-201AD (Through-Hole)
-
Operating Temperature Range: -55 °C to +150 °C
-
Category: Semiconductors, Discrete Semiconductors, Diodes & Rectifiers
The S36 Schottky Diodes & Rectifiers are built to provide low power loss and stable performance in demanding power electronic environments.
Key Features of S36 Schottky Diodes
-
Low forward voltage drop for higher efficiency
-
Fast recovery time ideal for high-frequency circuits
-
High surge current handling for durability
-
Through-hole DO-201AD package for robust mounting
-
Wide operating temperature range for industrial applications
These features make S36 a reliable choice among Schottky Diodes & Rectifiers in the Discrete Semiconductors category for both commercial and industrial power systems.
Applications
The S36 Schottky Diodes & Rectifiers are widely used in:
-
Switching power supplies and rectification circuits
-
DC-DC converters and voltage regulation modules
-
Solar panels and battery charging systems
-
Reverse polarity protection circuits
-
Consumer electronics and control systems
Their efficiency and fast switching characteristics make them valuable components in modern Semiconductors applications.
Wiring and Connection Overview
Typical wiring for S36 Schottky Diodes & Rectifiers:
This simple wiring configuration makes the S36 easy to integrate into rectifier bridges, converters, and protection circuits.
Use Case Scenario: Efficient Power Supply Rectification
Scenario: A power supply manufacturer required a diode capable of improving overall energy conversion efficiency.
Problem: Standard diodes had higher voltage drops, leading to heat and reduced performance.
Solution: Replacing them with S36 Schottky Diodes & Rectifiers by Yangjie improved efficiency and thermal performance.
Result: Lower power losses, cooler operation, and increased product lifespan.
Also available from other manufacturers
In addition to Yangjie, S36 Schottky Diodes & Rectifiers are also available from:
www.xonelec.com provides sourcing flexibility by offering multiple manufacturers to meet design and supply needs.
Download Datasheet for S36
Looking for detailed electrical and thermal specifications?
Download S36 Datasheet from Xon Electronics
Why Buy from Xon Electronics?
Xon Electronics offers a wide range of Semiconductors, including Discrete Semiconductors and Schottky Diodes & Rectifiers, with:
-
100% Genuine Components
-
Global Shipping – USA, India, Australia, Europe & more
-
OEM & bulk order pricing
-
Technical support and reliable sourcing
-
Secure online purchasing and fast worldwide delivery
Order S36 today at www.xonelec.com and experience trusted global component sourcing.
FAQs – S36 Schottky Diodes & Rectifiers
Q1. What is the reverse voltage of S36?
60 V.
Q2. How much forward current can it handle?
Up to 3 A continuous.
Q3. What package does S36 use?
DO-201AD through-hole package.
Q4. Is S36 suitable for solar and converter circuits?
Yes, its low forward voltage and fast switching make it ideal.
Q5. Can I purchase S36 globally?
Yes, www.xonelec.com ships to USA, India, Australia, Europe, and other countries.
Conclusion
The S36 Schottky Diodes & Rectifiers by Yangjie deliver outstanding efficiency, low power loss, and fast switching capabilities, making them a top choice for power supply, converter, and rectification circuits. Their durability and global availability make them suitable for a wide range of modern Semiconductors applications.
Available now at Xon Electronics with worldwide shipping to USA, India, Australia, Europe, and more.
