Introduction
The Schottky Diodes & Rectifiers SB520 by Diotec are high-efficiency Semiconductors designed for low forward voltage drop and fast switching applications. These Discrete Semiconductors are widely used in power supply circuits, converters, and protection applications where performance and compactness are essential.
Engineered for robust operation and long service life, the SB520 series ensures excellent power conversion efficiency, making it a preferred choice for engineers worldwide. This blog explores its technical details, applications, and how to purchase globally from www.xonelec.com.
Technical Specifications of SB520
-
Manufacturer: Diotec
-
Part Number: SB520
-
Type: Schottky Diodes & Rectifiers
-
Reverse Voltage (VR): 20 V
-
Forward Current (IF): 5 A
-
Forward Voltage Drop (VF): = 0.55 V
-
Package: DO-201AD (Through-Hole)
-
Operating Temperature: -55 °C to +150 °C
-
Category: Semiconductors, Discrete Semiconductors, Diodes & Rectifiers
The SB520 Schottky Diodes & Rectifiers provide excellent thermal stability, low power loss, and reliable performance, making them ideal for a wide variety of electronic designs.
Key Features of SB520 Schottky Diodes
-
Low forward voltage drop for improved power efficiency
-
High current handling capability (5 A)
-
Fast recovery time suitable for high-frequency applications
-
Robust DO-201AD through-hole package
-
Broad operating temperature range for diverse environments
These features make the SB520 a versatile choice among Discrete Semiconductors for industrial and consumer electronic systems.
Applications
The SB520 Schottky Diodes & Rectifiers are commonly used in:
-
DC-DC converters and switching power supplies
-
Battery chargers and reverse polarity protection circuits
-
Solar inverters and renewable energy systems
-
LED lighting power regulation
-
Automotive electronics modules
Its low forward voltage characteristics help reduce energy loss and heat generation in high-current circuits.
Wiring and Connection Overview
Typical wiring for SB520 Schottky Diode:
This simple wiring enables easy integration of SB520 into rectifier assemblies, converters, and protection circuits.
Use Case Scenario: Efficient DC-DC Converter
Scenario: A power electronics company required a diode solution for a compact DC-DC converter design.
Problem: Standard rectifiers caused excessive voltage drop and heat buildup.
Solution: Switching to SB520 Schottky Diodes & Rectifiers by Diotec provided low power loss and improved conversion efficiency.
Result: Enhanced performance, reduced heat, and higher reliability in continuous operation.
