TC4427AEOA713 Gate Drivers by JSMSEMI – Buy Online at XON
The Gate Drivers TC4427AEOA713 by JSMSEMI are high-performance dual MOSFET drivers designed for efficient switching in power electronics applications. As part of the Semiconductors, Integrated Circuits - ICs, Power Management ICs, Gate Drivers category, they deliver robust output current, fast rise and fall times, and high noise immunity—making them ideal for industrial, automotive, and embedded designs.
1. Technical Specifications of TC4427AEOA713
-
Manufacturer: JSMSEMI
-
Part Number: TC4427AEOA713
-
Type: Gate Drivers
-
Configuration: Dual high-speed MOSFET driver
-
Supply Voltage Range: 4.5V to 18V
-
Peak Output Current: ±1.5A
-
Propagation Delay: 55 ns (typical)
-
Operating Temperature: -40°C to +125°C
-
Package: 8-SOIC
-
Category: Semiconductors, Integrated Circuits - ICs, Power Management ICs, Gate Drivers
Engineered for precision and reliability, the TC4427AEOA713 ensures optimal gate drive for MOSFET and IGBT switching in demanding applications.
2. Key Features of TC4427AEOA713 Gate Drivers
-
Dual high-speed MOSFET driver outputs
-
Wide operating voltage range for design flexibility
-
Low propagation delay for fast switching
-
High peak output current capability
-
Robust thermal and short-circuit protection
3. Applications of TC4427AEOA713
-
DC-DC converters and SMPS
-
Motor control systems
-
Industrial automation equipment
-
Power inverters and converters
-
High-speed switching circuits
4. Wiring and Connection Overview
Typical connection setup:
-
Vdd: Connect supply voltage (4.5V–18V)
-
Inputs: Drive signals from controller/MCU to IN A and IN B
-
Outputs: OUT A and OUT B to MOSFET/IGBT gates
-
Ground: Common GND for driver and power circuit
5. Use Case Scenario – Industrial DC-DC Converter
Scenario: An OEM manufacturer required a compact, high-speed driver for a high-frequency DC-DC converter.
Problem: Previous drivers had slower switching speeds, reducing efficiency.
Solution: The TC4427AEOA713 Gate Drivers offered faster propagation delays and strong drive currents.
Result: Improved efficiency, reduced heat generation, and increased system reliability.
