ABM3-40.000MHZ-D2Y-T Abracon

CERAMIC SMD CRYSTAL Pb in Glass, exemption 7C-I per RoHS II Directive RoHS/RoHS II Compliant. ABM3 2011/65/EU Annex 5.0 X 3.2 X 1.3mm Smaller package alternative for ABM7 series Moisture Sensitivity Level (MSL) This product is Hermetically Sealed and not Moisture Sensitive - MSL = N/A: Not Applicable FEATURES: APPLICATIONS: AT-cut fundamental or 3rd OT mode Cellular telephones, pagers Suitable for RoHS reflow profile Communication and test equipment Tight Stability available 10 PCMCIA and wireless applications Ceramic package hermetically glass sealed assures high precision and reliability. STANDARD SPECIFICATIONS: Parameters Minimum Typical Maximum Units Notes 8.000 54.000 Fundamental Frequency Range MHz rd 54.100 80.000 3 Overtone rd Operation Mode Fundamental or 3 Overtone Operating Temperature -10 +60 C See options Storage Temperature -40 +90 C Frequency Tolerance +25C -50 +50 ppm See options Frequency Stability over the Operating -50 +50 ppm See options Temperature ( ref. to +25C) 8.000 F < 9.000 (Fund) 140 9.000 F < 10.000 (Fund) 120 10.000 F < 16.000 (Fund) 60 16.000 F < 20.000 (Fund) Equivalent series resistance (R1) 40 20.000 F < 30.000 (Fund) 30 30.000 F 54.000 (Fund) 25 rd 54.000 < F 80.000 (3 OT) 60 Shunt capacitance (C0) 7 pF Standard (See options if other Load capacitance (CL) 18 pF than STD) Drive Level 10 100 W 25C3C Aging -5 +5 ppm First year Insulation Resistance 500 M 100Vdc 15V 5101 Hidden Creek Ln Spicewood TX 78669 ABRACON IS Phone: 512-371-6159 Fax: 512-351-8858 ISO9001-2015 REVISED: 05-03-21 For terms and conditions of sales, please visit: CERTIFIED www.abracon.comMINIATURE CERAMIC SMD CRYSTAL Pb in Glass, exemption 7C-I per RoHS II Directive RoHS/RoHS II Compliant. ABM3 2011/65/EU Annex 5.0 X 3.2 X 1.3mm OPTIONS OPTIONS AND PART IDENTIFICATION:AND PART IDENTIFICATION: (Left blank if standard) ABM3 - MHz - - - - Frequency in MHz Packaging Please specify the frequency in MHz. Blank: Bulk e.g. 14.31818MHz T: Tape & Reel Load Capacitance (pF) Freq. Stability Please specify CL in pF (See Table 1 for details) or S for series U: 10 ppm G: 15 ppm Custom ESR if other X: 20 ppm than standard Operating Temp. Freq. Tolerance W: 25 ppm R (See Table 1 for details) 7: 15 ppm Y: 30 ppm : Specify a value in E: 0C ~ +70C 2: 20 ppm H: 35 ppm (e.g.: R40) B: -20C ~ +70C 3: 25 ppm Q: 100 ppm C: -30C ~ +70C 4: 30 ppm N: -30C ~ +85C D: -40C ~ +85C J: -40C ~ +105C K: -40C ~ +125C Table 1 Available Combinations of Operating Temp. and Freq. Stability Freq. Stability Operating Temp. U:10ppm G:15ppm X:20ppm W:25ppm Y:30ppm H:35ppm Std:50ppm Q:100ppm Std: -10C ~ +60C E: 0C ~ +70C B: -20C ~ +70C C: -30C ~ +70C N: -30C ~ +85C D: -40C ~ +85C J: -40C ~ +105C K: -40C ~ +125C 5101 Hidden Creek Ln Spicewood TX 78669 ABRACON IS Phone: 512-371-6159 Fax: 512-351-8858 ISO9001-2015 REVISED: 05-03-21 For terms and conditions of sales, please visit: CERTIFIED www.abracon.com
