PZU13BL,315 Nexperia

PZUxBL series Single Zener diodes in a SOD882 package Rev. 2 11 November 2019 Product data sheet 1. Product profile 1.1. General description General-purpose Zener diodes in a SOD882 leadless ultra small Surface-Mounted Device (SMD) plastic package. 1.2. Features Non-repetitive peak rerverse power dissipation: P 40 W ZSM Total power dissipation: P 250 mW tot Tolerance series: B: approximately 5 % B2: approximately 2 % Wide working voltage range: nominal 2.4 V to 36 V (E24 range) Low reverse current I range R Small plastic package suitable for surface-mounted design AEC-Q101 qualified 1.3. Applications General regulation functions 1.4. Quick reference data Table 1. Quick reference data Symbol Parameter Conditions Min Typ Max Unit V forward voltage I = 100 mA 1 - - 1.1 V F F P non-repetitive peak 2 - - 40 W ZSM reverse power dissipation P total power dissipation T 25 C 3 - - 250 mW tot amb 4 - - 550 mW 1 Pulse test: t 300 s 0.02 p 2 t = 100 s square wave T = 25 C prior to surge p j 3 Device mounted on an FR4 Printed-Circuit Board (PCB), single-sided copper, tin-plated and standard footprint. 2 4 Device mounted on an FR4 PCB, single-sided copper, tin-plated, mounting pad for cathode 1cm .Nexperia PZUxBL series Single Zener diodes in a SOD882 package 2. Pinning information Table 2. Pinning Pin Description Simplified outline Symbol 1 cathode 1 A K 1 2 2 anode 006aaa152 Transparent top view 1 The marking bar indicates the cathode 3. Ordering information Table 3. Ordering information Type number Package Name Description Version PZU2.4BL to PZU36BL DFN1006-2 leadless ultra small plastic package SOD882 1 2 terminals PZU2.7B2L to PZU24B2L 2 1 The series consists of 29 types with nominal working voltages from 2.4 V to 36 V. 2 The series consists of 25 types with nominal working voltages from 2.7 V to 24 V. PZUXBL SER All information provided in this document is subject to legal disclaimers. Nexperia B.V. 2019. All rights reserved Product data sheet Rev. 2 11 November 2019 2 / 12
