20SEF180M Panasonic

Conductive Polymer Aluminum Solid Capacitors Radial Lead Type SEF series Features High voltage (35 V max.) Large capacitance (1000 F max.) RoHS compliance, Halogen free Specifications Size code C6 E7 E12 F13 Category temp. range 55 to +125 Rated voltage range 16 V to 35 V Nominal cap.range 22 F to 180 F 39 F to 270 F 82 F to 560 F 120 F to 1000 F Capacitance tolerance 20 % (120 Hz / +20 ) DC leakage current Please see the attached characteristics list Dissipation factor (tan ) Please see the attached characteristics list +125 1000 h, rated voltage applied Capacitance change Within 20 % of the initial value Endurance Dissipation factor (tan) 200 % of the initial limit DC leakage current Within the initial limit +60 , 90 % to 95 % RH, 1000 h, No-applied voltage Capacitance change Within 20 % of the initial value Damp heat (Steady state) Dissipation factor (tan) 150 % of the initial limit DC leakage current Within the initial limit (after voltage processing) Marking Dimensions (not to scale) Polarity marking () d Lot No. Series code* 15 min. 4 min. L max. 19 min. R. capacitance Unit (F) R. voltage Size code D0.5 L max. F0.5 d0.05 (V) C6 6.3 6.0 2.5 0.5 *1 E7 8.0 7.0 3.5 0.5 E12 8.0 12.0 3.5 0.6 F13 10.0 13.0 5.0 0.6 * Depends on the case size. *1: 32SEF68M 0.60.05 Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. 24-Jan-20 D FSEF series Characteristics list Case size Specifications (mm) Part number Rated Rated capacitance Size Allowable voltage Ripple *2 *4 code ripple (20 %) ESR *3 LC Click here for part number *1 (V) D L tan current *1 list of lead terminal cutting (F) (m max.) (A) current (mA rms) and lead terminal taping (mA rms) 180 6.3 6.0 C6 1040 3300 22 0.12 576 16SEF180M 270 8.0 7.0 E7 1040 3300 22 0.12 864 16SEF270M 16 560 8.0 12.0 E12 1560 4950 14 0.12 1792 16SEF560M 1000 10.0 13.0 F13 1700 5400 12 0.12 3200 16SEF1000M 120 6.3 6.0 C6 1010 3200 25 0.12 480 20SEF120M 180 8.0 7.0 E7 1010 3200 25 0.12 720 20SEF180M 20 390 8.0 12.0 E12 1560 4950 14 0.12 1560 20SEF390M 560 10.0 13.0 F13 1700 5400 12 0.12 2240 20SEF560M 56 6.3 6.0 C6 880 2800 30 0.12 280 25SEF56M 82 8.0 7.0 E7 940 3000 28 0.12 410 25SEF82M 25 180 8.0 12.0 E12 1470 4650 16 0.12 900 25SEF180M 330 10.0 13.0 F13 1580 5000 14 0.12 1650 25SEF330M 32 68 8.0 7.0 E7 1010 3200 25 0.10 435 32SEF68M 22 6.3 6.0 C6 820 2600 35 0.12 154 35SEF22M 39 8.0 7.0 E7 880 2800 30 0.12 273 35SEF39M 35 82 8.0 12.0 E12 1260 4000 20 0.12 574 35SEF82M 120 10.0 13.0 F13 1390 4400 18 0.12 840 35SEF120M *1: Ripple current (100 kHz / +105 < Tx +125 ) / Allowable ripple current (100 kHz / Tx +105 ) *2: ESR100 kHz to 300 kHz / +20 *3: tan (120 Hz / +20 ) *4: After 2 minutes Please refer to each page in this catarog for Flow conditions and Taping specifications. Frequency correction factor for ripple current Frequency(f) 120 Hz f < 1 kHz 1 kHz f < 10 kHz 10 kHz f < 100 kHz 100 kHz f < 500 kHz Coefficient 0.05 0.3 0.7 1 Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. 24-Jan-20
