Technical data // PT65 5 01 L508 - Rotary Code Switch Left angular 5.08mm pitch Highlights Solid PCB pins Contacts with abrasion resistant hard gold plating Extra sealed design Switches are solder and flux sealed and washable Excellent detent, once more improved 100 % electronic inspection and testing Mechanical Data Type vertical Fixation mode THT Height 10.0 mm Length 11.88 mm Width 10.0 mm Pin connection 3+3 Perm. ambient temperature -20 C ... +70 C Perm. storage temperature -40 C ... +85 C Torque (typically) 1.7 Ncm Mechanical lifetime 30.000 steps Degree of protection comparable IP67 Sealing O-Ring Humidity 21 days at 40 C, 93 %RH Wave soldering Double Wave acc. DIN EN 61760-1:2006 Iron soldering 2 s / 340 C Sinus-vibration testing acc. IEC 68-2-6 Frequency range 10 Hz ... 500 Hz ... 10 Hz, sliding Amplitude 6.0 mm Acceleration 10.0 g Shock testing acc. IEC 68-2-27 Shock acceleration amplitude 50.0 g Duration of nominal shock 11.0 ms Directions 6 (x, y, z) 3 times each PTR HARTMANN GmbH Gewerbehof 38 59368 Werne, Germany Tel. +49 2389 7988-0 Fax +49 2389 7988-88 info ptr-hartmann.com www.ptr-hartmann.comTechnical data // PT65 5 01 L508 - Rotary Code Switch Left angular 5.08mm pitch Electrical Data Operating voltage <= 42.0 V Standby current <= 0.2 A Contact load, dynamic <= 0.15 A Minimum load 1.0 A 20mVDC Test voltage 250.0 V 50 Hz / 1.0 min Contact resistance < 80.0 mOhm Insulation resistance > 100.0 MOhm Technical Drawing Configuration Actuators Segment wheel PTR HARTMANN GmbH Gewerbehof 38 59368 Werne, Germany Tel. +49 2389 7988-0 Fax +49 2389 7988-88 info ptr-hartmann.com www.ptr-hartmann.com
