CRCW02016M80FNED

CRCW0201 e3 www.vishay.com Vishay Lead (Pb)-free Commodity Thick Film Chip Resistors FEATURES High volume product suitable for commercial applications Pure tin solder contacts on Ni barrier layer provides compatibility with lead (Pb)-free and lead containing soldering processes Metal glaze on high quality ceramic Material categorization: for definitions of compliance please see www.vishay.com/doc 99912 STANDARD ELECTRICAL SPECIFICATIONS LIMITING ELEMENT CASE CASE POWER RATING TEMPERATURE RESISTANCE VOLTAGE TOLERANCE MODEL SIZE SIZE P COEFFICIENT RANGE SERIES 70 U % max. INCH METRIC W ppm/K AC /DC RMS V 200 10.0 to 10M 0.5 E24 E96 -200 / +400 1.0 to 9.76 100 47.0 to 1M 0.05 30 200 1 10.0 to 10M E24 E96 CRCW0201 0201 RR 0603M -200 / +400 1.0 to 9.76 200 10.0 to 10M 5 E24 -200 / +400 1.0 to 9.1 Zero-Ohm-Resistor: R = 50 m , I at 70 C = 1.0 A max. max. Notes These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime. Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material. TECHNICAL SPECIFICATIONS PARAMETER UNIT CRCW0201 (1) Rated Dissipation at 70 C W0.05 Operating Voltage U AC /DC V 30 max. RMS Insulation Voltage U (1 min) V 50 ins 9 Insulation Resistance > 10 Operating Temperature Range C -55 to +155 Weight mg 0.17 Note (1) The power dissipation on the resistor generates a temperature rise against the local ambient, depending on the heat flow support of the printed-circuit board (thermal resistance). The rated dissipation applies only if the permitted film temperature of 155 C is not exceeded. Revision: 07-Mar-17 Document Number: 20052 1 For technical questions, contact: thickfilmchip vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 CRCW0201 e3 www.vishay.com Vishay PART NUMBER AND PRODUCT DESCRIPTION PART NUMBER: CRCW02011K00FNED C R C W 0 2 0 1 1 K 0 0 F K E D MODEL VALUE TOLERANCE TCR PACKAGING CRCW0201 R = decimal D = 0.5 % K = 100 ppm/K ED K = thousand F = 1.0 % N = 200 ppm/K EE M = million J = 5.0 % X = -200 ppm/K / +400 ppm/K EI 0000 = jumper Z = jumper 0 = jumper PRODUCT DESCRIPTION: CRCW0201 100 1K0 1 % ET7 e3 CRCW0201 100 562R 1 % ET7 e3 RESISTANCE TOLERANCE MODEL TCR PACKAGING LEAD (Pb)-FREE VALUE VALUE CRCW0201 200 ppm/K 1R0 = 1 0.5 % ET7 e3 = pure tin 100 ppm/K 10R = 10 1 % EF4 termination finish - 200/+ 400 ppm/K 1K0 = 1 k 5 % ET2 10K = 10 k 1M0 = 1 M 0R0 = jumper PACKAGING MODEL CODE QUANTITY CARRIER TAPE WIDTH PITCH REEL DIAMETER ED = ET7 10 000 180 mm/7 Paper tape acc. CRCW0201 EI = ET2 20 000 to IEC 60068-3 8 mm 2 mm 254 mm/10 Type I EE = EF4 50 000 330 mm/13 DIMENSIONS in millimeters SIZE DIMENSIONS SOLDER PAD DIMENSIONS INCH METRIC L W H T1 T2 a b l 0201 0603 0.6 0.05 0.3 0.05 0.23 0.05 0.15 0.05 0.10 0.05 0.28 0.43 0.23 Note No marking for 0201 size. Revision: 07-Mar-17 Document Number: 20052 2 For technical questions, contact: thickfilmchip vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
