Models 601, 602 Battery Capacity Analyzers Data Sheet Battery capacity Analyzers 601 602 Models 601, 602 B+K Precision Battery Capacity Analyzers tests Lead Acid Batteries and displays the batteries stored charge capacity as a percentage and dis- plays both the batteries loaded and un-loaded battery voltage. Models 601 and 602 can also display the battery under tests internal rsistance. These units identify batteries, which may be defective or deteriorated. They are perfect tools for testing battery back up systems for emergency lighting, alarm, sprinkler systems, UPS devices and any system using lead acid batteries to provide power. Specifications Models 601 602 Testable Battery Voltages 6 & 12V 24 & 36V (42V) Max. Input Voltage 20V 50V Selectable Amp Hours 1 - 100AH in 1AH steps Dimensions (WxHxD) 3.14 x 9.5 x 1.6 (80 x 240 x 40mm) Specifications subject to change without notice B&K Precision Corporation 22820 Savi Ranch Parkway, Yorba Linda, CA 92887 Tel: 714-921-9095, Fax: 714-921-6422 www.bkprecision.com
