TDA7492 STMicroelectronics

TDA7492 50 W + 50 W dual BTL class-D amplifier Datasheet - production data Description The TDA7492 is a dual BTL class-D audio amplifier with single power supply designed for LCD TVs and monitors. Thanks to the high efficiency and exposed-pad-up (EPU) package, only a simple heatsink is required. PowerSSO-36 with exposed pad up Features 50 W + 50 W continuous output power at THD = 10% with R = 6 and V = 25 V L CC 40 W + 40 W continuous output power at THD = 10% with R = 8 and V = 25 V L CC Wide-range single-supply operation (8 - 26 V) High efficiency ( = 90%) Four selectable, fixed gain settings of nominally 21.6 dB, 27.6 dB, 31.1 dB and 33.6 dB Differential inputs minimize common-mode noise Standby and mute features Short-circuit protection Thermal overload protection Externally synchronizable ECOPACK , environmentally friendly package Table 1. Device summary Order code Operating temp. range Package Packaging TDA7492 -40 to +85 C PowerSSO-36 EPU Tube TDA749213TR -40 to +85 C PowerSSO-36 EPU Tape and reel January 2015 DocID014926 Rev 6 1/32 This is information on a product in full production. www.st.comContents TDA7492 Contents 1 Device block diagram 6 2 Pin description . 7 2.1 Pinout . 7 2.2 Pin list . 8 3 Electrical specifications 9 3.1 Absolute maximum ratings . 9 3.2 Thermal data . 9 3.3 Electrical specifications . 9 4 Characterization curves . 11 4.1 Characterizations for 6- loads 11 4.2 Characterizations for 8- loads 15 4.3 Characterizations for 4- loads 18 4.4 Test board . 21 5 Applications circuit . 22 6 Applications information 23 6.1 Mode selection . 23 6.2 Gain setting . 24 6.3 Input resistance and capacitance . 24 6.4 Internal and external clocks . 25 6.4.1 Master mode (internal clock) . 25 6.4.2 Slave mode (external clock) . 25 6.5 Output low-pass filter 26 6.6 Protection functions . 27 6.7 Diagnostic output . 27 6.8 Heatsink requirements . 28 7 Package mechanical data . 29 2/32 DocID014926 Rev 6
