CM1241-04D4 ON Semiconductor

CM1241 4-Channel Low Capacitance Dual-Voltage ESD Protection Array Features CM1241 PACKAGE / PINOUT DIAGRAMS Table 1. PIN DESCRIPTIONS 4 Channel, 8Lead, WDFN8 Package Top View Bottom View Pin Name Type Description (Pins Down View) (Pins Up View) 8 7 6 5 1 CH1 I/O LV Lowcapacitance ESD Channel 12 3 4 2 CH2 I/O LV Lowcapacitance ESD Channel 3 CH3 I/O LV Lowcapacitance ESD Channel AW1 DAP Pin 1 4 V HV V HV ESD Channel CC DD Marking 5 GND Ground 87 6 5 1 2 3 4 6 V Negative Voltage Supply Rail N 8Lead WDFN 7 V Negative Voltage Supply Rail N 8 V Negative Voltage Supply Rail N DAP GND Die Attach Pad (Ground) SPECIFICATIONS Table 2. ABSOLUTE MAXIMUM RATINGS Parameter Rating Units DC Voltage on Lowvoltage Pins 6.0 V DC Voltage on Highvoltage Pins (V pin) 14.5 V CC Operating Temperature Range 40 to +85 C Storage Temperature Range 65 to +150 C Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability. Table 3. STANDARD OPERATING CONDITIONS Parameter Rating Units Operating Temperature Range 40 to +85 C
