Is Now Part of To learn more about ON Semiconductor, please visit our website at www.onsemi.com Please note: As part of the Fairchild Semiconductor integration, some of the Fairchild orderable part numbers will need to change in order to meet ON Semiconductors system requirements. Since the ON Semiconductor product management systems do not have the ability to manage part nomenclature that utilizes an underscore ( ), the underscore ( ) in the Fairchild part numbers will be changed to a dash (-). This document may contain device numbers with an underscore ( ). Please check the ON Semiconductor website to verify the updated device numbers. The most current and up-to-date ordering information can be found at www.onsemi.com. Please email any questions regarding the system integration to Fairchild questions onsemi.com. ON Semiconductor and the ON Semiconductor logo are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductors product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent-Marking.pdf. ON Semiconductor reserves the right to make changes without further notice to any products herein. ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. Buyer is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards, regardless of any support or applications information provided by ON Semiconductor. Typical parameters which may be provided in ON Semiconductor data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including Typicals must be validated for each customer application by customers technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor was negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.FGA6065ADF 650 V, 60 A Field Stop Trench IGBT May 2015 FGA6065ADF 650 V, 60 A Field Stop Trench IGBT Features General Description o Maximum Junction Temperature : T = 175 C This ADF IGBT series adopted Field Stop Trench 3rd genera- J tion IGBT which offer extreme low Rds(on) and much faster Positive Temperaure Co-efficient for Easy Parallel Operating switching characteristics for outstanding efficiency. And this kind High Current Capability of technology is fully optimized to variety PFC (Power Factor Low Saturation Voltage: V = 1.8 V (Typ.) I = 60 A CE(sat) C Correction) topology Single boost, Multi channel interleaved 100% of the Parts Tested for I (1) LM etc with over 20KHz switching performance. TO3P package High Input Impedance provide Super Low thermal resistance for much wider SOA for system stability. Fast Switching RoHS Compliant Applications PFC topology for Home appliance : Single Boost , Multi chan- nel Interleaved etc. PFC Topology for Welder C G G C TO-3PN E E Absolute Maximum Ratings Symbol Description FGA6065ADF Unit V Collector to Emitter Voltage 650 V CES Gate to Emitter Voltage 20 V V GES Transient Gate to Emitter Voltage 30 V o Collector Current T = 25C120 A C I C o Collector Current T = 100C60 A C o I Pulsed Collector Current T = 25 C 180 A LM (1) C I Pulsed Collector Current 180 A CM (2) o Diode Forward Current T = 25C60 A C I F o Diode Forward Current T = 100C30 A C I Pulsed Diode Maximum Forward Current 120 A FM (2) o Maximum Power Dissipation T = 25C306 W C P D o Maximum Power Dissipation T = 100C153 W C o T Operating Junction Temperature -55 to +175 C J o T Storage Temperature Range -55 to +175 C stg Maximum Lead Temp. for soldering o T 300 C L Purposes, 1/8 from case for 5 seconds Notes: 1. V = 400 V, V = 15 V, I =180 A, R = 48.4 Inductive Load CC GE C G 2. Repetitive rating: Pulse width limited by max. junction temperature 2015 Fairchild Semiconductor Corporation 1 www.fairchildsemi.com FGA6065ADF Rev. 1.0
