Product Information

C2073B

Product Image X-ON

Datasheet
Transistors (NPN/PNP) TO-220 RoHS
Manufacturer: FeiHong
This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges



Price (USD)

1: USD 0.3425 ea
Line Total: USD 0.3425

0 - Global Stock
MOQ: 1  Multiples: 1
Pack Size: 1

 More Buying Options & Price Grid(s)

Availability Price Quantity
0 - Global Stock


Ships to you between
Wed. 21 Jun to Mon. 26 Jun

MOQ : 1
Multiples : 1

Stock Image

C2073B
FeiHong

1 : USD 0.3425
10 : USD 0.2835
30 : USD 0.2407
100 : USD 0.2055
500 : USD 0.1993
1000 : USD 0.1964

Read More Specifications


Manufacturer
FeiHong
Product Category
Bipolar Transistors - BJT
Brand
Feihong
Rohs
Y
Package
TO - 220
Current - Collector Ic Max
1.5 A
Voltage - Collector Emitter Breakdown Max
150 V
Power - Max
25 W
Collector Cut-Off Current Icbo
10 uA
Collector-Emitter Breakdown Voltage Vceo
150 V
Power Dissipation Pd
25 W
Collector Current Ic
1.5 A
Dc Current Gain Hfe@Ic Vce
70@500 mA , 5V
Transition Frequency Ft
-
Collector-Emitter Saturation Voltage Vcesat@Ic Ib
1 V @500 mA , 50 mA
Transistor Type
-
Operating Temperature
+ 150 C @ (Tj)
Show Stocked Products With Similar Attributes. LoadingGif

More Products By Manufacturer "Feihong"

Image Description
Stock Image FHP20200A
200V Dual Common Cathode 880mV@10A 10A TO-220 Schottky Barrier Diodes (SBD) ROHS
Stock : 1
Stock Image FHP740A
400V 11A 193.6W 640mO@10V,5.5A N Channel TO-220 MOSFETs ROHS
Stock : 3
Stock Image FHS150N1F4A
New Quadratic Unclassified Data TO-263 RoHS
Stock : 10
Stock Image FHF7N65A
650V 7A 35W 1.3O@10V,3.5A N Channel TO-220F-3 MOSFETs ROHS
Stock : 1
Stock Image FHF10N65B
650V 10A 50W 900mO@10V,5A N Channel TO-220F-3 MOSFETs ROHS
Stock : 4
Stock Image FHF10N65A
650V 10A 50W 900mO@10V,5A N Channel TO-220F-3 MOSFETs ROHS
Stock : 6
Stock Image FHU4N60A
600V 4A 75W 2.1O@10V,2A N Channel TO-251 MOSFETs ROHS
Stock : 5
Stock Image FHF12N65C
650V 12A 54W 750mO@10V,6A N Channel TO-220F-3 MOSFETs ROHS
Stock : 1
Stock Image FHF5N65B
650V 5A 30W 2.8O@10V,2A N Channel TO-220F-3 MOSFETs ROHS
Stock : 15
Stock Image FHP12N60A
600V 12A 231W 750mO@10V,6A N Channel TO-220 MOSFETs ROHS
Stock : 1

More Products By Category "Bipolar Transistors - BJT"

Image Description
Stock Image KSP05TA

Bipolar (BJT) Transistor NPN 60 V 500 mA 100MHz 625 mW Through Hole TO-92-3
Stock : 1

Hot Stock Image MMBT4126LT1G

Bipolar (BJT) Transistor PNP 25 V 200 mA 250MHz 225 mW Surface Mount SOT-23-3 (TO-236)
Stock : 1

Stock Image MMBT200

Bipolar Transistors - BJT PNP Transistor General Purpose
Stock : 1

Stock Image BC807DS,115

Transistors Bipolar - BJT TRANS DOUBLE TAPE-7
Stock : 1

Stock Image BCP52

Bipolar (BJT) Transistor PNP 60 V 1.2 A 1.5 W Surface Mount SOT-223-4
Stock : 1

Stock Image BC848CDW1T1G

Transistors Bipolar - BJT 100mA 30V Dual NPN
Stock : 1

Stock Image KSC2330YTA

Bipolar (BJT) Transistor NPN 300 V 100 mA 50MHz 1 W Through Hole TO-92-3
Stock : 1

Stock Image 2SC3326-A,LF

Bipolar Transistors - BJT Transistor for Low Freq. Amplification
Stock : 1

Stock Image 2SC4117-BL,LF

Bipolar Transistors - BJT Transistor for Low Freq. Amplification
Stock : 1

Stock Image 2N4401

Trans GP BJT NPN 40V 0.6A 3-Pin TO-92 Bulk
Stock : 1

Additional Infomation About Product

TRANSISTOR C2073B MAIN CHARACTERISTICS FEATURES IC 1.5A Epitaxial silicon VCEO 150V High switching speed PC 25W RoHS RoHS product A940 Complementary to A940 APPLICATIONS High frequency switch power supply Commonly power amplifier circuit High frequency power transform Package ABSOLUTE RATINGS (Tc=25 ) Symbol Parameter Value Unit VCBO 170 V Collector- Base Voltage IE=0 VCEO- 150 V Collector- Emitter Voltage IB=0 VEBO 7 V Emitter-Base Voltage IC=0 IC 1.5 A Collector Current DC PC 25 W Total Dissipation (TO-92) Tj 150 Junction Temperature Tstg -55~+150 Storage Temperature 1 Ver-1.0 ELECTRICAL CHARACTERISTICS Parameter Tests conditions (min) (typ) (max) Unit V(BR)CBO IC=100uA,IE=0 170 - - V V(BR)CEO IC=2mA,IB=0 150 - V V(BR)EBO IE=100uA,IC=0 7 - - V ICBO VCB=180V, IE=0 - - 10 A IEBO VEB=7V, IC=0 - - 10 A hFE(1) VCE =5V, IC=0.5A 70 - 200 - VCE(sat) IC=0.5A, IB=0.05A - - 1 V = atu 2 Ver-1.0
