MPS8098
MPS8099
www.centralsemi.com
DESCRIPTION:
NPN SILICON TRANSISTOR
The CENTRAL SEMICONDUCTOR MPS8098 and
MPS8099 types are NPN silicon transistors designed for
general purpose audio amplifier applications.
PNP complementary types are MPS8598 and
MPS8599.
MARKING: FULL PART NUMBER
TO-92 CASE
MAXIMUM RATINGS: (T =25C) SYMBOL MPS8098 MPS8099 UNITS
A
Collector-Base Voltage V 60 80 V
CBO
Collector-Emitter Voltage V 60 80 V
CEO
Emitter-Base Voltage V 6.0 V
EBO
Continuous Collector Current I 500 mA
C
Power Dissipation P 625 mW
D
Operating and Storage Junction Temperature T , T -65 to +150 C
J stg
Thermal Resistance 200 C/W
JA
ELECTRICAL CHARACTERISTICS: (T =25C) MPS8098 MPS8099
A
SYMBOL TEST CONDITIONS MIN MAX MIN MAX UNITS
I V =Rated V - 0.1 - 0.1 A
CBO CB CBO
I V=60V - 0.1 - 0.1 A
CEO CE
I V=6.0V - 0.1 - 0.1 A
EBO EB
BV I=100A 60 - 80 - V
CBO C
BV I=10mA 60 - 80 - V
CEO C
BV I=10A 6.0 - 6.0 - V
EBO E
V I =100mA, I=5.0mA - 0.4 - 0.4 V
CE(SAT) C B
V I =100mA, I=10mA - 0.3 - 0.3 V
CE(SAT) C B
V V =5.0V, I=1.0mA 0.5 0.7 - - V
BE(ON) CE C
V V =5.0V, I=10mA - - 0.6 0.8 V
BE(ON) CE C
h V =5.0V, I=1.0mA 100 300 100 300
FE CE C
h V =5.0V, I=10mA 100 - 100 -
FE CE C
h V =5.0V, I=100mA 75 - 75 -
FE CE C
f V =5.0V, I =10mA, f=100MHz 150 - 150 - MHz
T CE C
C V =5.0V, I =0, f=1.0MHz - 6.0 - 6.0 pF
ob CB E
C V =0.5V, I =0, f=1.0MHz - 25 - 25 pF
ib EB C
R2 (27-August 2012)MPS8098
MPS8099
NPN SILICON TRANSISTOR
TO-92 CASE - MECHANICAL OUTLINE
LEAD CODE:
1) Emitter
2) Base
3) Collector
MARKING:
FULL PART NUMBER
R2 (27-August 2012)
www.centralsemi.com
